Model 604
PARTS LIST FOR MODEL 604 EDGER
>EF.
0.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
720-0120
Black Grip
45
781-0076
Guard Ass'y.
2
712-0107
Hex L.-Nut 1/4-20 Thd.
46
781-0080
Edger Blade¿2..iTtu/Di: y 1 Laa& L
3Ó4. .
3
714-0115
Cotter Pin 1/8” Dia. x 1.00" Lg.*
47
712-0287
Hex Nut 1/4-20 Thd.*
4
710-0106
Hex Bolt 1/4-20 x 1.25" Lg.*
48
736-0329
L.-Wash. 1/4" I.D.*
5
710-0380
Hex Bolt 5/16-18
X
1.75" Lg.*
49
712-0287
Hex Nut 1/4-20 Thd.*
6
749-0666
Engagement Handle
50
736-0329
L.-Wash. 1/4" I.D.*
7
781-0081
Adjustment Bracket
51
781-0078
Spindle Plate Ass'y.
8
732-0369
Compression Spring .50" O.D.
52
15319
Bearing Housing 1-3/8" I.D.
X
1.38" Lg.
53
741-0155
Ball Bearing .62" I.D. x 1.38" O.D.
9
736-0264
FI.-Wash. .344" I.D. x .62" O.D.
54
710-0258
Hex Bolt 1/4-20 x.62" Lg.*
X
.063
55
756-0449
3/8" "V"-Pulley 2"
X
5/8" I.D.
10
712-0158
Hex Cent. L.-Nut 5/16-18 Thd.
56
754-0142
"V"-Belt •Vi'X
3 1 - ^ 0
11
747-0498
Clutch Rod Half 3/8" Dia. x
57
710-0929
Hex Bolt 5/8-18x4.50" Lg.*
18.25" Lg.
58
710-0289
Hex Bolt 1/4-20 x .50" Lg.*
12
710-0111
Carriage Bolt 1/4-20 x 1.25" Lg.*
59
781-0086
Belt Guard
13
14
750-0628
712-0287
Rod Adjustment Link
Hex Nut 1/4-20 Thd.*
60
750-
SPACER. .fcSS" ZD X, 9l"lD ?
15
736-0329
L.-Wash. 1/4" I.D.*
61
712-0267
Hex Nut 5/16-18 Thd.*
16
09955
Lower Handle
62
736-0242
Bell.-Wash. .345" I.D. x .88" O.D.
17
714-0122
Sq. Key 3/16" x 3/16" x .75" Lg.
63
714-0121
Spring Pin Spir. 1/4" Dia. x 2.00"
Lg.
18
712-0798
Hex Nut 3/8-16 Thd.*
64
781-0090
Pivot Bracket Ass'y.
19
736-0169
L.-Wash, 3/8" I.D.*
65
710-0600
Hex Wash. Hd. Self Tap Scr.
20
756-0327
Engine Pulley
5/16-24
X
.50" Lg.
21
750-0212
Spacer .75" I.D.
66
781-0075
Arm Extension
22
736-0258
Fl.-Wash. .385" I.D. x 1.0" O.D.
67
781-0093
Adjustment Lever Ass'y.
23
710-0152
Hex Bolt 3/8-24
X
1.0" Lg.*
68
732-0188
Torsion Spring
24
734-0841
Rear Wheel Ass'y. 8 x 1.75
69
712-0267
Hex Nut 5/16-18 Thd.*
25
738-0108
Shoulder Bolt .498" Dia. x 1.45" Lg.
70
736-0119
L.-Wash. 5/16" I.D.*
■^6
13960-463
Belt Guard Ass'y.
71
750-0622
Spacer .50" I.D. x .62" O.D. x
7
732-0187
Compression Spring
1.62" Lg.
28
711-0379
Bushing
72
738-0613
Axle .50" Dia. x 8.75" Lg.
29
712-0267
Hex Nut 5/16-18 Thd.*
(Front)
30
736-0119
L.-Wash. 5/16" I.D.*
73
781-0083
Base Ass'y.
31
715-0247
Spring Pin Spir. 3/16" Dia;
X
1.00"
74
714-0101
Hair Pin Cotter 1/2" Dia.
Lg.
75
710-0442
Hex Bolt 5/16-18
X
1.50"
32
712-0287
Hex Nut 1/4-20 Thd.*
Lg.*
33
736-0112
Bell.-Wash. .535" I.D. x 1.50"O.D.
76
734-0840
Front Wheel Ass'y. 7 x 1.50
34
71/1 ^ni 1 K
Cotter Pin 1/8" Dia. x 1.00" Lg.
77
Engine
35
712-0114
Hex Slotted Nut 1/2-20 Thd.
78
726-0192
Cable Tie
36
736-0329
L.-Wash. 1/4" I.D.*
79
749-0667
Upper Handle
37
781-0087
Flap Bracket
80
710-0597
Hex Bolt 1/4-20X 1.00" Lg.*
38
736-0342
Fl.-Wash. .25"!.D. x .75" O.D. x
81
781-0092
Handle Support Plate
.030
82
831-0692
Throttle Control Box Ass'y.
39
710-0289
Hex Bolt 1/4-20X .50" Lg.*
83
746-0421
Throttle Control Wire 30" Lg.
40
731-0725
Flap
84
726-0221
Push Cap 1/2" Dia.
41
710-0402
Hex Bolt 5/16-18
X
4.5" Lq.*
85
711-0386
Spacer .386" I.D. x .510" O.D. x
42
750 - 0118 4rLeHve . fc32" XO x,875 ÓD x. 9
3.765" Lg.
86
781-0095
Debris Deflector: .25" Lg.
43
736-0317
Bell.-Wash. .630" I.D. x 1.25" O.D.
87
710-0118
Hex Bolt 5/16-18
X
.75" Lg. Spec.
44
712-0221
Hex Ins. L.-Nut 5/8-18 Thd.
88
711-0699
Stud 1/4-20
X
2.12" Lg.
89
710-0779
Self-Tap Scr. #10 x .50" Lg.
ot
*For faster service order standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
463 — Topflite Red
621 — Brilliant Fire Mist (24604)
When ordering parts, if color or finish is important, use the appropriate color,
code shown at left. (e.g. Topflite Red 10112 (4631.)
NOTE; The engine is not under warranty by
NOTE
the edger manufacturer . .
If repairs or
service is needed on the engine, please
contact your nearest author-
This instruction manual covers various models
ized engine service outlet.
Find It Fast
and all specifications shown do not necessari-
Check the "Yellow Pages" of
In The
ly apply to your model. Specifications subject
your telephone book under
Yellow Pages
to change without notice or obligation.
'‘Engines—Gasoline.”
