_________________REPAIR PARTS — BASE AND PULLEYS
Drawing No. 91356
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 86318 1 Mounting Base 43 75710-A 1 Oil Fill and Drain Tube
2 90141 1 Ground Cable 44 74958 1 Cap and Dipstick Assembly
3 46911 4 Rubber Mount 45 67871 1 0-ring Cap
4 25017 8 3/8"-16x 1/2“ Capscrew 46 75712 1 0-ring Drain
5 46526 10 M10 Lock Washer 47 75711 1 0-ring Adaptor
6 22129 2 M8 Lock Washer 56 73179 1 Oil Fitter Support
7 72391 2 Rubber Mount Skid 57 70185 1 Oil Filter (FRAM PH #3614)
8 77603 2 5/16“-18x 3-1/2" Bolt 58 77667 1 Oil Pressure Switch
9 22259 2 5/16-18 Hex Nut 59 74948 3 5/16" Fitting
10 52858 6 M8-1.25 Flanged Lock Nut 60 74950 1 Outer Oil Tube
11 51730 2 M8-1.25 X 60mm Capscrew 61 74951 1 Inner Oil Tube
12 29459 Z Belt Tension Spring 62 73134 1 Oil Pad Adaptor
13 75215 2 Spring Center Washer 63 38750 3 M6-1.00 X 30mm Capscrew
14 73146 4 Nylon Slide 64 74949 1 5/16" 90-degree Fitting
15 75209 2 Nylon Slide Support 65 68548 1 Oil Pad Gasket
16 73174 1 Exhaust Manifold 66 62684 1 Grounding Lug
17 79678 2 Exhaust Manifold Gasket 67 29289 — 1/16" X 8’ Foam Tape
18 55173 4 M8-1.25 X 20mm Capscrew 69 75281 1 High Temperature Switch
19 72383 2 Collector Pan Gasket 70 74027 2 M3-0.5 Pan Head Screw
20 90859 1 Cover Plate - External 71 43182 2 M3 Lock Washer
21 75224-F 1 Engine Pulley 73 75237 4 Spring Retainer Washer
22 73106-F 1 Alternator Pulley 74 77681 1 LOS 2-wire Vinyl Cap
23 75216 1 40" Poly Vinyl 4L Belt 75 75474 1 17“x42"x2" Vinyl Cap
24 49451 1 Pulley Retainer Washer 76 90800 1 Exhaust Elbow
25 42633 1 3/8"-24 X 1" Capscrew 77 74907 1 1-1/8" Exhaust Clamp
26 77017 1 Blower Housing Guide 78 75226 1 Air Cover
27 73118 1 3/8"-24 X 2-1/2" Capscrew 79 56893 14 #10-24 X 1/2* Screw
28 74906 5 M6-1.00 X 20mm Screw 80 75229 1 Slide Pan Gasket
29 91123 1 Fuei Pump Bracket 81 75227 1 Slide Pan
30 72375 1 Blower Housing 82 79246 8 M6-1.0 X 16mm Capscrew
31 73185 1 Blower Housing Spacer
with lock washer
32 22097 6 M6 Lock Washer
83 22473 4 M6 Flat Washer
33 77682 1 M5-0.8 X 80mm Capscrew
85 72384-C 1 Exhaust Outlet Cover •
34 75242 4 Generator Mounting Spring
87 77643 2 Exhaust Outlet Gasket
35 49813 2 M6-1.00HexNut
90 22447 1 M8 Toothed Lock Washer
36 45757 2 M6-1.0 X 25mm Capscrew
91 90088 1 Vinyl Coated Clamp
37 90475 1 Fuel Pump
92 74908 10 M5-0.8 X 10mm Screw
38 87769 1 Fuel Filter
93 81105 2 5/16'-18 Flange Nut (special)
39 87768 1 1/8" Pipe to 1/4“ Tube Fitting
94 23897 6 M5 Flat Washer
40 87770 1 Fuel Line
95 67210 1 Decal — Ground
42 26925 1 3/8“ NPT Oil Drain
96 45756 9 M6 X 10mm Taptite Screw
97 22131 1 M10 Flat Washer
