NOTE
Reference to left or right side of thi
tiller is determined from behind th<
unit in the operating position.
Tailpiece
ASSEMBLY INSTRUCTIONS
NOTE
This unit is shipped WITHOUT GAS
OLINE or OIL. After assembly, see
operating section of this manual for
proper fuel and engine oil recom
mendations.
Tools Required:
(2)
1
/
2
" Socket, Open or Box Wrench
(2) 9/16" Socket, Open or Box Wrench
Parts in Carton:
Tiller
Handle Panel*
Depth Bar
-Tailpiece
Handles*
Hardware Pack
figure
1.
FIGURE 2.
Remove These
Bolts
Contents of Hardware Pack: (See Figure 2)
A (4) Carriage Bolts 5/16-18 x 1.75" Long*
B (4) Lock Washers 5/16" I.D.*
C (4) Hex Nuts 5/16-18 Thread*
D (2) Hex Bolts 3/8-16 x 1.00" Long
E (2) Belleville Washers
F (2) Lock Washers 3/8" I.D.
-G (2) Hex Nuts 3/8-16 Thread
H (1) Clevis Pins
I (1) Hairpin Cotters
J (2) Cable Ties
K (1) Self-Tapping Screw (Not Shown)
*May be preassembled on your unit.
Remove the tiller, all loose parts and literature from the
carton before discarding carton.
Extend the throttle control and place on the floor. Be
careful not to bend or kink control wire.
TAILPIECE INSTALLATION
1.
Remove two hex bolts located on the rear of tiller
------- frame. See figure 3. A 9/16" wrench is required.
FIGURE 3.
