CONTENTS OF HARDWARE PACK

Parts Bag contents shown full size

(1) Hex Bolt

3/8-16 X 1

(1) Large Flat Washer

'' '

^

(1) Lockwasher 3/8

(1) Locknut

5/16-18

(1) Hex Bolt 5/16-18

X

1-1/4

o

(1) Shoulder Bolt 5/16-18

(1) Hex Bolt 1/2-13 x 1

(1) Lock Washer 1/2

(1) Washer 17/32 x 1-3/16 x 12 Gauge

(2) Hex Bolts 1/4-20 x 3/4

(2) Hex Nuts 1/4-20

(2) Lock Washers 1/4

(2) Washers 9/32 x 5/8 x 16 Gauge

Parts packed separately in carton

Seat

Steering

Sleeve

Steering Wheel

Manual

Parts Bag

Parts bag contents not shown full size

(2) Shoulder Bolts

(2) Washers 17/32

X

15/16

X

12 Gauge

(2) Gauge

Wheels

(2) Center-

lock Nuts

Steering

Wheel

i

^ I Ipgg^

0

o

(2) Washers 3/8

X

7/8

X

14 Gauge

Steering

Extension

Shaft

Slope Sheet

—1 —,3—

Steering Wheel

Adapter

(2) Keys
