MODELS 63QC, 634A & 634K
REF
NO.
PART NO.
DESCRIPTION
REF
NO.
PART NO.
DESCRIPTION
1
736-0159
Flat Washer, 5/16
(B)
23
710-0520
HexHd. Screw, 3/8-16x1-1/2
2
714-0139
Key, 3/16" X 2-
24
710-0599
Screw, Self-Tapping, 1/4-20 x 1/2
1108841
Key, 3/16"
X
1.5”
(C)
25
710-3103
HexHd. Screw, 5/16-18x2(6)
3
1916531
Pulley, Engine Drive
26
712-3000
Lock Nut, 3/8-16
619-04016
Pulley, Engine Drive
(C)
27
712-3009
Lock Nut, 5/16-18(6)
4
1916532
Transmission Pulley
(8)
28
736-0119
Lock Washer, 5/16
656-04023
Transmission Pulley
(A)
29
736-3050
Flat Washer, 3/8
5
1916535
Pulley, Reverse Idler
(B)
30
736-3090
Flat Washer
6
1916652
Guard, Belts/Pulleys
31
710-0151
Hex Hd. Screw, 3/8-24 x 2.00
7
1916657
Forward Drive Belt
710-0459A
HexHd. Screw, 3/8-24x 1.50
(C)
8
1916658
Reverse Drive Belt(B)
32
GW-1138-2
Shim(D)
9
1916660
Belt Cover
736-0315
Flat Washer,.75 x
1
.5 x.125
(A)
10
1916724
Reverse Return Spring
(B)
33
GW-50027
Support Washer
11
1916725
Reverse Belt Guide
(B)
34
GW-55034
Forward Return Spring
12
1916726
Forward Belt Guide
35
GW-55049
Bracket, Cable Mounting
13
1916794
Engine Bracket, Left
36
GW-9090
Forward Idler Pulley
14
1916795
Engine Bracket, Right
37
GW-9301
Key, 3/16" xf
15
1917326
Bracket, Belt Cover
38
736-3078
Flat Washer
16
1917746
Shoulder Washer
39
GW-9944
Belleville Washer
17
1918731
Reverse Idler Arm
(B)
40
710-0672
HexHd. Screw, 5/16-24x1.25
(A)
18
1918744
Forward Idler Lever
41
710-0805
HexHd. Screw, 5/16-18x1-1/2
(A)
19
710-0117
Hex Hd. Screw, 5/16-24x1
42
712-3010
Hex Nut, 5/16-18
(A)
20
710-0237
Hex Hd. Screw, 5/16-24x5/8
43
736-0242
BellWasher,.340x.872x.060(A)
21
710-0376
Hex Hd. Screw, 5/16-18x1
44
736-0452
Bell Washer,.396x 1.140 X.095
22
710-04049
Hex Hd. Screw, 5/16-18x5/8
45
750-0258
Spacer,.315x.750x375 Lg
(A)
(A)
For Model 630C
(B)
For Model 634A and 634K
(C)
For Model 634K Only
(D)
For Model 634A Only
