6.2. Connector Descriptions
X1
Power Input
Pin Signal
Pin Signal
1
8-30V DC-Input
2
Ground
X2
ATX Connector
Pin Signal
Pin Signal
1
+3.3V
2
+3.3V
3
GND
4
+5V
5
GND
6
+5V
7
GND
8
PWR-OK
9
+5VSB
10 +12V
11 +3.3V
12 -12V
13 GND
14 PS-ON#
15 GND
16 GND
17 GND
18 -5V
19 +5V
20 +5V
X11
LVDS
Pin Signal
Pin Signal
1
LVDS_A0-
2
LVDS_A0+
3
GND
4
GND
5
LVDS_A1-
6
LVDS_A1+
7
LCD BKL (dep. J5)
8
LCD BKL (dep. J5)
9
LVDS_A2-
10 LVDS_A2+
11 LCD VDD (dep 3)
12 LCD VDD (dep 3)
13 LVDS_A3-
14 LVDS_A3+
15 NC
16 NC
17 NC
18 NC
19 LVDS_Clock-
20 LVDS_Clock+
The LVDS interface works only if the J6 Jumper is not installed.
X14
Video Input Channel
Pin Signal Name
Function
in/out
1
Video Signal
CVBS
In
2
Ground
The Video IN interface works only if the J6 Jumper is installed.
