DIGITAL-LOGIC AG
MSEBX800/900 Detailed Manual V1.0
15
2.5. MSEBX800/900 Specifications
CPU
Specification
CPU SM800
AMD GEODE LX800/900 located in the smartModule800/900
CPU Core Supply
1.25V very low powered
1
st
Level Cache
32k data and 32k code
2
nd
Level Cache
128kByte
Performance
SM800PCX
SM900PCX
P2 Equivalent Performance:
500MHz
600MHz
Clock
SM800PCX
SM900PCX
The CPU Clock is defined with the ordered SM800/900-xxx
500MHz
600MHz
Chipset
Specification
Northbridge
AMD LX800/900
Southbridge
AMD CS5536
LAN
2x 10/100Mbit Intel 82551ER (LAN A), Intel 82551ER (LAN B)
Audio
Stereo In and Stereo Line-Out
Codec
AD1985 up to 96kHz sampling rate, 16bit (Analog Devices)
Firewire IEEE1394
Not on board
Video
16MByte Video-DDRAM
Memory
Specification
SODIMM
SODIMM200pin DDR PC2700 333MHz 256-1024MByte
Flash-BIOS
8MByte Flash
Setup EEPROM
2kByte for CMOS-backup in battery-less applications
Flash-Video BIOS
Combined in the core BIOS
Video RAM
16MByte to 64MByte DDRAM
Video Controller
Specification
Controller
AMD graphics integrated in the LX800/900 chipset
Video Memory
16MB
Channel 1
CRT VGA up to 2048x1600 pixels
Channel 2
LVDS, TV-Out, CRT
Bootup-Resolution
640x480 / 800x600 / 1024x768
2D-Graphics
Integrated accelerator
3D-Graphics
None
Direct-X Version
-
PnP
Integrated
