î
REF
NO.
. PART
NO.
DESCRIPTION
NO.
REO'D.
REF.
NO.
PART
NO.
DESCRIPTION
NO.
REO'D.
1
12056
Height Control Plunger
1
26
12111
Blade Brake Arm
1
2
10248
Shift Ball
1
27
83010
Spring
1
3
83015
Spring
1
28
12062
Blade Brake Support
1
4
12170
Mower Height Quadrant
1
29
3117
Reinforcing Plate
1
5
59022
Screw 5/16"-18
X
3/4"
2
30
54073
Bearing
2
6
67004
Cotter Pin 1/8"
X
1"
5
31
3172
Spindle Housing
1
7
12117
Height Link Rod
1
32
59004
Cap Screw 3/8"-16 x 1" H.H.
6
8
12112
Height Control Arm
1
33
66003
Key, #9 Woodruff
2
9
56007
Roll Pin 1/4"
X
1-1/4"
1
34
3127
Mower Spindle
1
10
83027
Spring
1
35
3419
Bearing Slinger
1
n
12113
Floating Link
1
36
3169
Retainer Hub
1
12
12125
Adapter Pin
1
37
3170
Blade Tray
1
13
12165
Mower Pan
1
38
3165
Mower Blade
1
14
63003
Lockwasher
2
39
12116
Rear Raising Bracket
1
15
65015
Locknut 5/16"-18 Plated
2
40
12115
Clevis
1
16
65025
Hex Jam Nut 3/4"-10 Plated
2
41
12059
Rear Bracket Pin
1
17
63008
Lockwasher 3/4"
2
42
12067
Rear Harder Rod
1
18
12061
Mower Belt Finger
1
43
64003
Wrought Washer 1/2"
1
19
65039
Locknut 3/8"
7
44
12114
Clevis
1
( 20
69002
Washer
2
45
64039
Washer 1.005 O.D. x ,630 I.D.
X
.062 1
21
72029
V-Belt
1
46
65049
Nut 5/8"-18 Slotted Jam
1
22
12025
Mower Sheave
1
47
67014
Cotter Pin 1/8"
X
1-1/4"
1
23
68016
Rivet 1/4"
X
1/2" Rd. Hd.
1
(NOT ILLUSTRATED)
24
12063
Blade Brake
1
78160
Safety Label
1
25
3016
Shoulder Bolt
1
78028
Discharge Caution Label
1
