Ariens FAIRWAY PM 12000 - Manual (Page 11)

Ref.
No.
Part
No,
Description
No.
Req'd.
Ref.
No.
Part
No.
Description
No.
Req'd.
/ / /
o> 0» >> 0» 0»
70009 Screw, Flange Whizlock 5/16-18 x 1/2 10 10 10 62 12129 Bushing 2 2 2
2 12147 Rear Belt Finger 1 1 1 63 612999 Differential Assembly 1 1 1
3 63003 Lockwasher 5/16 S.A.E. Std. 8 8 8 64 3017 Bearing Flange 2 2 2
4 59003 Cap Screw 5/16-18 x 1 H.H. 1 1 1 65 54093 BaU Bearing 2 2 2
5 12204 Engine Sheiave 1 1 66 10142 Bearing Flange 2 2 2
5 12024 Engine Sheave 1 67 612007 L. H. Axle Assembly 1 1 1
6 72048 V-Belt 1 1 1 68 70005 Wheel Bolt 6 6 6
7 66009 Key, Woodruff #6 1 1 1 69 67004 Cotter Pin 1 / 8 x 1 2 2 2
8 64043 Washer 1 1 70 64007 Washer 1/4 Std. 2 2 2
8 64028 Washer 1-1/8 O.D. x 7/16 LD. x 3/16 1 71 12006 Drive Spring Housing 1 1 1
9 63004 Lockwasher 3/8 S.A.E. Std. 3 3 3 72 12027 Carrier 1 1 1
10 59017 Cap Screw 3/8-24 x 1-1/4 H.H 1 1 1 73 58030 RoU Pin 1 1 1
11 12086 Cap 3 3 3 74 12180 Locating Plate 1 1 1
12 3159 Hitch Shaft 1 1 1 75 59069 Cap Screw 5/16-18 x 1-1/4 H.H. 1 1 1
13 3254 Wave Washer 2 2 2 76 83026 Idler Spring 1 1 1
14 3252 Hitch 1 1 1 77 12142 Idler Arm 1 1 1
15 65054 Locknut 1/2-20 Hex Jam 2 2 2 78 12131 Bearing Spacer 1 1 1
16 12026 Brake Drum 1 1 1 79 12132 Idler 1 1 1
17 12033 Brake Band 1 1 1 80 64002 Washer 5/16 Std. 1 1 1
18 59039 Cap Screw 5/16-18 x 1/2 H.H.. 2 2 2 81 12094 Shift Transfer Lever 1 1 1
19 83082 Spring 1 1 1 82 12151 Clevis Pin 1 1 1
20 12074 Brake Band Washer 1 1 1 83 12096 Shift Link 1 1 1
21 12196 Brake Spacer 1 1 1 84 12136 Zerk FitUng 1 1 1
22 60018 Setscrew 1/4-20 x 1/2 Square Head 1 1 1 85 12095 Sliding Fork 1 1 1
23 3074 Set Collar 1 1 1 86 3086 BaU Joint 1 1 1
24 12032 Brake Rod 1 1 1 87 65056 Nut 6 6 6
25 67001 Cotter Pin 3/32 X 3/4 2 2 2 88 12190 Spindle Cup 1 1 1
26 55047 Bushing 4 4 4 89 70014 Cap Screw, Special 1 1 1
27 12182 Clutch Brake Bellcrank 1 1 1 90 54039 BaU Bearing 2 2 2
28 10354 Zerk Fitting 2 2 2 91 12100 Bearing Spacer 1 1 1
29 3085 Bearing Flange 2 2 2 92 12010 Drive Spindle Housing 1 1 1
30 54080 Bearing Flange 2 2 2 93 12199 Disc Fork 1 1 1
31 3031 Bearing Flange 2 2 2 94 10522 Screw Pin 2 2 2
32 65051 Nut #10-24 8 8 8 95 612003 Drive Spindle Assembly 1 1 1
33 66015 Key, Woodruff #5 2 2 2 96 10132 Fork Spacer 1 1 1
^34 12029 Hex Shaft 1 1 1 97 55029 Bushing 2 2 2
35 57043 Snap Ring 1 1 1 98 612002 Tire and Wheel Assembly 2
36 54083 Bearing 1 1 1 Consisting of:
37 3003 Friction Wheel 1 1 1 1 - 71052 Rim
38 12183 Friction Wheel Hub 1 1 1 1 - 71081 Tire
39 12152 Zerk Fitting 2 2 2 1 - 71050 Tube
40 10276 Sprocket 1 1 1 98 612006 Tire and Wheel Assembly 2 2
•41 12078 Chain 1 1 1 Consisting of:
42 65015 Nut 2 2 2 1 - 71090 Tire
43 12150 Pin 1 1 1 1 - 71091 Rim
44 12013 Cap 1 1 1 *1 - 71089 Tube is avaUable
45 83055 Spring 1 1 1
46 12014 Spring Retainer 1 1 1
47 59036 Cap Screw 5/16-24 x 1/2 H.H. 1 1 1 (NOT ILLUSTRATED)
48 56034 Seal 2 2 2
49 12181 Carrier Shaft 1 1 1
50 64039 Washer 1.005 O.D. x .630 LD. x .062 2 2 2 78003 Mower In-Out Label 1 1 1
51 54038 Needle Bearing 2 2 2 78018 Mower Shift Label 1 1 1
52 12141 Pinion and Sprocket 1 1 1 78172 Engine Label 1 1 1
53 12039 Disc Fork Rod 1 1 1 78192 Engine Decal 7 H.P. 1 1
54 58016 RoU Pin 3/16 X 1 1 1 1 78193 Engine Decal 5 H.P. 1
55 3377 Hub Cap 4 4 4 78195 Fairway Nameplate 2 2 2
56 10366 Pushnut 1 1 1 78206 Caution Decal 1 1 1
57 3376 Spindle Cup 1 1 1 78207 Mower Caution Label 1 1 1
58 12215 R. H. Axle 1 1 1 78209 Height Quadrant Label 1 1 1
59 58003 RoU Pin 3/16 X 1-1/4 1 1 1 78210 Parking Brake Decal 1 1 1
60 64036 Washer 1.380 O.D. x .880 LD. x .062 2 2 2
61 65042 Locknut 5/16-18 Hex 2 2 2
Page 11
