N

5. With thé friction wheel assembly out of the frame, the

three cap screws holding the friction wheel to the hub
may be removed and the friction wheel removed.

6. Position a new friction wheel on the hub and secure with

the three cap screws. Tighten securely.

7. Slip the right end of the complete friction wheel assembly

and hex shaft into the hole in the right side of the frame.
Position the friction wheel hub in the forks. Be sure
washers are in place on bearing flange pins. Slide the hex
shaft to the left and into the left bearing being Sure flat
washer is in position. See that the pinion gear meshes with
the large gear.

8. Replace the bearing flange on the right side of the frame

and secure with the four carriage bolts and nuts. Reconnect
the traction clutch rod in the clutch fork arm and secure
with a hair pin cotter. Readjust the traction clutch as
de»;ribed above.

FLATWASHE

(OUTSIDE OF(jk.
PINION)

1/8

3

/

16

'

FIGURE?

SNO-THRO UNIT

The blower gear case is lubricated with Ariens Liquid

Grease (Part No. 000070). This grease will not flow at lower
temperatures. It is therefore difficult to check the lubricant
level. Best method for checking is to place the unit in a warm

location overnight. This allows the grease to flow to level.

Check the lubrication by removing the filler plug on the side
of the gear case just above the left auger shaft. Lubrication
should be even with the hole with the machine sitting level. It
may be necessary to insert a wire into the hole to check level.
The unit will not be damaged by over lubricating.

SHEAR BOLT«

TRACTION

CLUTCH

rod

:

FIGURES

LUBRICATION

ENGINE

Fill crankcase with Ariens Sno-Thro oil 5W-20 when

using Sno-Thro.

Use Ariens Gard-N-Yard oil MS classification SAE-30 when
using lawn attachments.

Refer to engine owners manual for appropriate crankcase oil

substitutes.

Fill fuel tank (

r

) with fresh, clean unleaded automotive

gasoline. (Leaded "regular" grade gasoline is an acceptable
substitute.)

NOTE: For detailed instructions on engine refer to manu­

facturer's booklet packed with the machine.

TRACTOR DRIVE

At the start' of season, grease hex shaft as indicated in Figure

7. Use Ariens Moly Lithium grease.

Put two or three drops of light oil on shift lever and other
linkage points. CAUTION: Do not allow grease or oil to

come in contact with friction wheel, drive disc or belts.

SHAFT

FILLER PLUG

FIGURES

Oil rake shaft periodically or each time a shear bolt is re­
placed. At the end of the season, remove shear bolts, oil
rake shaft through shear bolt holes, turn rakes on shaft

several times and replace shear bolts.

Oil the discharge chute with several drops of heavy oil.

STORAGE

ENGINE — Follow detail instructions in the Engine Manual.

SNO-THRO — Lubricate, clean and repaint as necessary.
Cover and store in dry place.

-7-
