Ariens SNO- THROS 932007 - Manual (Page 11)

SNO-THRO PARTS LIST FOR MODELS 932001, 832002, 832003,932004 & 932006
SOUFFLEURS SNO-THRO MODELES 932001, 832002, 832003,932004 & 932006
N ode NO DE CODE
REF. PIECi D'INV
DESCRIPTION
REF. PART STOCK
NO. NO. CODE
O
o
CM
CO
O)
QUANTITÉ
NO. RÉQ'D
^ CM CO CO
o o o o
o o o o
CM CM CM CM
CO CO CO CO
O) 00 cn 00
N ode
REF.
REF.
NO.
No DE
PIECE
PART
NO.
CODE
D'INV.
DESCRIPTION
STOCK
CODE
o
o
CM
CO
O)
QUANTITÉ
NO. REQ'D
Tt CM to CO
o o o o
o o o o
CM CM CM CM
CO CO CO CO
cn OO O) 00
1 532010 BLOWER HOUSING 1 39 022081 CHUTE CONTROL CRANK 1 1
1 532003 BLOWER HOUSING 1 40 532004 BRACKET 1 1
2 010142 BEARING FLANGE 1 1 41 062001 CARRIAGE BOLT,y.-20x1'/4 1 1
3 054063 RAOiAL BEARING 1 1 42 062053 CARRIAGE BOLT,y4-20x'/2 5 5
4 003017 BEARING FLANGE 1 1 43 075039 GRIP 1 1
5 065040 LOCKNUT 4 4 44 010198 CAP 1 1
6 066001 KEY,Woodruff 3/16x7/8 1 1 45 532002 GEAR CASE ASSEMBLY 1
7 073103 SHEAVE 1 1 532011 GEAR CASE ASSEMBLY 1
8 060005 SET SCREW 2 2 46 032032 RH GEAR CASE 1 1
9 632014 BEARING FLANGE W/BUSHING 2 2 47 032033 LH GEAR CASE 1 1
10 055113 FLANGED BUSHING 2 2 48 055112 FLANGED BUSHING 2 2
11 064009 WASHER,3/4x1-3/8x.134 4 4 49 056043 SEAL 2 2
12 064128 WASHER,.338/.358x1-3/8x14 2 2 50 532001 FAN SHAFT 8. WORM GEAR 1 1
13 063003 LOCKWASHER 2 2 51 058003 ROLL PIN,3/16 x 1’/4 1 1
14 059002 CAPSCREW,5/16-18x5/8 2 2 52 032035 THRUST COLLAR 1 1
15 070058 RIBBED NECK BOLT 6 6 53 055111 FLANGED BUSHING 1 1
16 065056 FLANGE WHIZLOCK NUT 6 6 54 032081 SCRAPER BLADE 1
17 010165 RUNNER 2 2 032067 SCRAPER BLADE 1
18 062010 CARRIAGE BOLT,3/8-16x3/4 4 4 55 056047 "0" RING 1 1
19 064002 WASHER,5/16x7/8x.083 4 4 56 032036 RAKE SHAFT 1
20 065039 LOCKNUT 4 4 032082 RAKE 1
21 022159 CHUTE,Discharge 1 1 57 066014 KEY,Woodruff 3/16x5/8 1 1
22 022160 GEAR LOWER COLLAR 1 1 58 002862 HUB 1 1
23 074034 SELF-TAPPING SCREW 6 6 59 „ J164lfiJ WASHFR, 757/7fi2x.1 74:i nfilR _2- _
24 522006 DEFLECTOR CHUTE 1 1 60 032038 GASKET 1 1
25 059039 CAPSCREW,5/16-18 x ’/2 2 2 61 062012 CARRIAGE BOLT,'/4-20xy4 4 4
26 065042 LOCKNUT 3 3 62 065056 FLANGE WHIZLOCK NUT 9 9
27 062034 CARRIAGE B0LT,5/16-18xy4 1 1 64 032040 FAN 1 1
28 064168 WASHER,5/16x7/8x1/16 NYLON 1 1 65 058007 ROLL PIN,y4x1'/4 2 2
29 064057 WASHE R,.312/.343x.625x.062 2 2 67 032041 RIGHT RAKE 1
30 070009 FLANGE WHIZLOCK SCREW 4 4 67 032083 RIGHT RAKE 1
31 013202 WAVE WASHER 1 1 68 032084 LEFT RAKE 1
32 022123 WORM CLEVIS 1 1 68 032042 LEFT RAKE 1
33 062011 CARRIAGE BOLT,5/16-18x% 1 1 69 532005 SHEAR BOLT 8. NUT 2 2
34 063032 LOCKWASHER 1 1 70 070053 RIBBED NECK BOLT 5/16-18xy4 3 3
35 063023 LOCKWASHER 1 1 71 065078 FLANGE WHIZLOCK NUT 3 3
36 065015 NUT 1 1 72 054112 FLANGE BUSHING 1 1
37 022110 WORM GEAR 1 1 73 070010 FLANGEWHIZLOCK 1 1
38 058034 R0LLPIN,1/8x3/4 1 1
SCREW,3/8-16 x ’/2
rH
SUGGESTED PARTS STOCKING CODE
F - FAST S - SLOW
M - MEDIUM O -CUSTOMER ORDER ONLY
CODE SUGGÉRÉ D'INVENTAIRE DES PIÈCES
F — FAST (rapide)
M - MEDIUM (moyen) S - SLOW (lent)
0 — Commande du client seulement
r-
-
11
-
