PARTS LIST FOR 4 HP TRACTOR
Part
No.
Description
No.
Req'd.
Part
No.
Description
No.
Req'd.
Part
No.
Description
No.
Req’d.
1027
Spring
2
10230
Clutch Rod
1
12X72
Capscrew 1/4-20 x 1-1/4
1
2033
Handle Bar Panel
1
10231
Shift Quadrant
1
12X73
Capscrew 5/16-18 x 1-3/4
1
2038
Clutch Handle
1
10232
Shift Handle
1
12X74
Capscrew 5/16-18 x 2/3/4
1
2044
Clutch Lock Spring
1
10233
Spring
1
14X12
Set Screw 5/16-18 x 3/8
2
2045
Clutch Lock Pin
1
10235
Shift Rod
1
20X2
Lockwasher 1/4 Std.
2
2402
Idler
1
10237
Chain
1
20X3
Lockwasher 5/16 Std.
10
3003
Friction Wheel
1
10239
Sheave
1
20X4
Lockwasher 3/8 Std.
4
3031
Bearing Flange
2
10240
Idler Arm Hub Spacer
1
21X2
Washer 5/16
15
3085
Bearing Flange
2
10241
Upper Handle Bar
1
21X7
Washer 1/4
1
3086
Ball Joint
1
10247
Ball Joint
1
21X33
Washer
1
5006
Key 3/16 Sq. x 1"
1
10248
Shift BaU
1
21X37
Washer
1
6071
Spacer
2
10266
Tractor Frame
1
21X38
Shim Washer
1 or 2
R-1271 Spacer Bushing
1
10267
Bearing Housing
1
21X42
Washer
2
10147
Bottom Cover
1
10272
Carburetor Cover (Not lUus.)
1
21X43
Washer
1
10156
R. H. Lower Handle Bar
1
10275
Hex Shaft
1
23X15
Nut 5/16-18
7
10157
L. H. Lower Handle Bar
1
10276
Sprocket
1
23X18
Nut 3/8-16
4
10158
Outer Belt Guard
1
10277
Friction Disc Hub
1
23X31
Nut 5/16-24
2
10159
Inner Belt Guard
1
10279
Axle Shaft
1
23X40
Locknut 1/4-20
8
10160
R. H. Belt Finger
1
10285
Connecting T.lnk
1
23X41
Locknut 3/16 10-24
8
10161
L. H. Belt Finger
1
10288
Hub Cap
2
23X42
Locknut 5/16-18
4
10194
Clutch Lever
1
10289
Eye Bolt Rod Hanger
1
23X43
Locknut 5/16-24
2
10196
Handle Bar Washer
2
10293
Shift Release Handle
1
23X54
Locknut 1/2-20
2
10202
Idler Arm
1
10294
Engine Sheave
1
23X56
Nut 1/4-20
6
10204
Spindle
1
12023
Bearing Support
2
24X11
Feather Key
2
10205
Drive Plate
1
1X63
Ball Bearing
2
24X12
Key #91 Woodruff
1
10206
Jaw Coupling
1
1X74
Thrust Bearing
1
24X15
Key #5 Woodruff
1
10207
Pinion & Sprocket
1
1X78
BaU Bearing
2
25X1
Cotter Pin 3/32
X
3/4
2
10208
Pinion Stub Shaft
1
2X26
Bushing
2
25X4
Cotter Pin 1/8x1
3
10209
Support Bracket
1
2X34
Bushing
2
25X10
Hair Cotter Pin
2
10211
Spur Gear
1
5X37
Retaining Ring
1
25X14
Cotter Pin 1/8
X
1-1/4
3
10212
Bracket Pin
1
5X43
Snap Ring
1
28X12
Cable Clamp
1
10213
Sliding Fork
1
8X8
Clevis Pin
1
28X32
Throttle Control
1
10214
Fork Shalt
1
9X16
Roll Pin 3/16 X 1
2
31X9
Flange Whizlock Screw 5/16-18 x 1/2
14
10215
Lever Bracket
1
12X22
Capscrew 5/16-18 x 3/4
3
31X10
Flange Whizlock Screw 3/8-16 x 1/2
4
10217
Transfer Lever
1
12X50
Capscrew 1/4-20 x 1-1/2
5
31X11
Ribbed Neck Bolt 1/4-20 x 5/8
6
10220
Clutch Bracket
1
12X53
Capscrew 5/16-24 x 3/4
2
33X62
Tire & Wheel Assembly
2
10222
Disc Bracket
1
12X56
Capscrew 1/4-20 x 1-1/4
2
34X89
Belt
1
10226
Neutral Catch
1
12X69
Capscrew 5/16-18 x 1-1/4
1
35X1
Self-Tapping Screw #10 x 1/2
4
10227
Throwout Lever
1
36X5
Grip 3/4
X
3-1/2
1
10228
Lower Shift Bod
1
36X6
Grip 1
X
4-1/2 or 5
2
