pecifications
Model Number
924318
924323
924324
924325
924326
Description
ST824
ST1024
ST1128E
ST1132E
ST1336E
Engine Tecumseh
HMSK-BO-155641V
HMSK-100-159391WOHSK.110-221702A
OHSK-130-223809B
Power Max - HP (Kw/min’)
8 (5.97)
10(7.46)
11 (8.2)
13 (9.7)
Max Rotation Speed - RPM (min'^)
3600
Displacement - in (cc)
19.43 (318.3)
21.82 (357.5)
19.43 (318.3)
21.82 (357.5)
Electric Start 12V Key Start
No
Yes
Fuel
See Engine Manual
Tank Capacity - qt (Liters)
4(3.8)
Snow Clearing Width - in (cm)
24 (61.0)
28 (71.2)
32 (81.3)
36 (91.4)
Snow Throwing Distance - ft (meters)
3-30 (0.9-9.1)
5-35 (1.5-10.5)
Chute
Rotation Angle
230°
Rotation Control at Handlebar
Yes
Dual Handle Interlock
Yes
Impeller
Speed - RPM - Max (min'^)
1100
Auger
Diameter - in (cm)
15(38.1)
16(40.6)
Speed - RPM - Max (min'^)
110
Auger Brake
Yes
Auger Clutch
Yes
Drive
Disc-0*Matic
Speeds
6 Forward and 2 Reverse
Lock Out Differential
Yes
Adjustment Skids
Yes
Pneumatic Tires - in (cm)
4.80/4.00x8(12.2/10.2x20.3)
16/6.50x8 (40.6/16.5x20.3)
Size and Weight
Length - in (cm)
60(152)
Height - in (cm)
40(101.6)
Width - in (cm)
26.3 (66.6)
30.5 (77.6)
38.5 (97.8)
Weight - tbs (Kg)
265 (120)
303 (138)
318(144)
341 (155)
CE Sound
Oper. Ear Sound Pressure (L^^) in dB^
88.9
90
90
90
90
Oper. Sound Power (L^J in dB^
104.8
103
101
101
103
Vibration Measure X
3.7
3.1
2.1
1.8
3.5
@ Operator Hands Y
4.3
3.5
3.1
2.6
2.9
Z
3.7
2.4
2.2
1.7
2.6
