REPAIR PARTS
12.5 HP 38" RIDING LAWN TRACTOR
STEERING, FRONT AXLE AND WHEELS
-MODEL NO. LT125
KEY PART DESCRIPTION KEY PART DESCRIPTION
.0. NO. NO NO.
1 532124416 Insert, Steering Wheel 25 532128758 Shaft, Steering
2 873940800 Nut, Hex Jam Toplock 1/2-20 26 532124035 Support Shaft
3 532100712 Washer 17/32 x 2-1/4 x .160 27 532132624 Pin, Axle
4 532124415 Steering Wheel 28 532124036 Bracket Assembly, Steering
5 532100711 Adapter, Steering Wheel 29 532124034 Gear, Sector
6 532109816 Nyliner, Snap-in 31 532126684 Washer, Shim
7 812000029 Ring, Klip 32 532124931 Bearing, Thrust _ ,
8 532121749 Washer 25/32 x 1-1/4 x 16 Ga. 33 . Shaft, Pitman -
9 532124959 Bearings, Wheel, Front 34 532130460 Spindle Assembly, L.H.
10 532106222 Tire 35 817490612 Screw, Hex Wasner Hd. Thread
11 532059904 Tube, Tire (Optional Service Item Forming Type TT 3/8-16 x 3/4
Only) 36 873601000 Nut, Flange 5/8-11
12 532125102 Rim Assembly 37 532124937 Bearing
(Inc. 2 each Key No. 9) 38 532124577 Cover, Wheel
13 532065139 Stem, Valve 39 532124957 Fitting, Grease
14 532059192 Cap, Valve 40 532121748 Washer 25/32 x 1-5/8 x 16 Ga.
15 532108075 Axle Assembly, Front 46 819111216 Washer 11/32 X 3/4 X 16 Ga.
16 874011056 Bolt, Hex 5/8-1 lUNCx 3-1/2 47 810040500 Washer, Lock 1/4
17 532130459 Spindle Assembly, R.H. 49 532057079 Washer
18 873810500 Nut, Hex Nylon 5/16-24 UNF 50 819272016 Washer 27/32 X -1/4x16Ga.
19 532130467 Tie Rod 51 532121232 Spindle Cap
20 532124836 Fitting, Grease 54 810040400 Washer, Lock
21 532110438 Spacer Bearing, Front Axle 55 871070410 Screw, Socket Hex
22 810040600 Lock Washer 3/8
23 873610600 Nut, Hex 3/8-24 NOTE: All component dimensions given in U.S. inch^
24 532130468 Drag Link 1 inch = 25.4 mm
37
