TROY-BILT® Roto Tiller-Power Composter—TUFFY^" MODEL
Page 5
TINE HOOD, DEPTH REGULATOR, AND DRAG BAR
Index
Part
No.
No.
No.
Description
Req’d
1
9552
BOLT—Flanged Head, Self-Tapping, V4-20 x V
2
".......................
2
2
Index No. 2 is not used.............................................................
3
55101
DECAL—Hood (contains operating and safety
instructions) .........................................................................
1
4
Index No. 4 is not used.............................................................
5
55076
TINE HOOD —(includes tine flap and decal 55101) ...
1
6
9550
BOLT—Hex Head, 5/16-18 x Va" ..............................................
2
7
9848
NUT—Flange Lock, 5/16-18 .....................................................
2
8
55074
DEPTH REGULATOR LEVER ........................................................
1
8A
9308
SPIROL PIN.......................... .....................................................
2
9
9384
SPRING—Depth Regulator..........................................................
1
10
9534
SPACER .....................................................................................
1
11
9734
BOLT—Hex Head, V4-20 XI"......................................................
1
12
9811
LOCKNUT—Hex, 74-20.............................................................
1
13
55072-2
BRACKET—Hood, Right Hand ....................................................
1
14
55072-1
BRACKET—Hood, Left Hand.......................................................
1
15
9912
LOCKWASHER, 5/16" ................................................................
2
16
90045
BOLT—Flanged Head, 5/16-18 x 1" ..........................................
2
17
9801
NUT—Hex, 5/16-18 .................................................................
2
18
9574
BOLT—Hex Head, 5/16-18 X 174" ............................................
2
19
55088
BUSHING—Drag Bar ..................................................................
2
20
55073
DRAG BAR ................................................................................
1
