TROY-BILT® Roto Tiller-Power Composter—TUFFY^" MODEL Page 11
TRANSMISSION HOUSING, COVERS, SEALS
GASKETS, AND PLUG
Index Part No.
No. No. Description Req’d
1 9467 PLUG—Transmission Oil Fill/Check..................................... .......... 1
2 9550 BOLT—Hex Head, 5/16-18 x V
2
"........................................ .......... 8
3 97037 GASKET—Transmission Oil Fill/Check Plug ........................ .......... 1
4 9912 LOCKWASHER—5/16"......................................................... .......... 8
5 55008 COVER—Transmission Housing, Front ............................... .......... 1
5A 50074 COVER—Transmission Housing, Rear.................................. .......... 1
6 50032 GASKET—Transmission Housing Cover,
(Front and Rear)...... ....................................................... .......... 2
7 9617 OIL SEAL—Driveshaft.......................................................... .......... 1
8 9621 OIL SEAL—Wheelshaft ........................................................ .......... 2
9 55000 TRANSMISSION CASE, REAR HOUSING, AND
TUBE ASSEMBLY .................................. ......................... .......... 1
10 97039 OIL SEAL—Tine Shaft......................................................... .......... 2
11 55011-1 GASKET—Bearing Cap (.010 thick)...................................... .......... 1
55011-2 GASKET—Bearing Cap (.030 thick)...................................... .......... 1
12 55010 CAP—Rear Bearing.............................................................. .......... 1
13 90045 BOLT—Flanged Head, 5/16-18 x 1" .................................. .......... 2
14 90044 BOLT—Flanged Head, 5/16-18 x %"................................... .......... 1
