Troy-Bilt 1900634A - Manual (Page 15)

TROY-BILT® Roto Tiller-Power Composter—TUFFY^” MODEL Page 13
Index Part
DRIVE SHAFT ASSEMBLY
No.
No. No. Description Req’d
1 9655 BOLT—Hex Head, 5/16-24 x Grade 5 .......................................... 1
2 9944 WASHER—Belleville........................................................................ 1
3 55031 PULLEY—Transmission..................................................... ........... 1
4 9301 KEY—Transmission Pulley, 3/16" x 1"........................................... 1
5 50027 SUPPORT WASHER—Front.................................................. ........... 1
6 9517 SNAP RING........................................................................ ........... 1
7 1714 BEARING—Tapered Roller with race ................................. ........... 2
8 50043 SUPPORT WASHER—Rear .................................................. ........... 1
9 55001 DRIVESHAFT ASSEMBLY .................................................... ........... 1
10 1224-1 SHIM—Rear Bearing Cap, .010 thick..................................
1224-2 SHIM—Same as above except 0.030 thick.........................
Req’d
........... As
1224-3 SHIM—Same as above except 0.005 thick.........................
Req’d
............ As
1224-4 SHIM—Same as above except 0.062 thick.........................
Req’d
............ As
1325C SHIM SET—Includes the following shims:
two #1224-1, two #1224-2, one
1224-3, and one #1224-4 ..........................................
Req’d
As
