TO LUBRICATE THE MACHINE
Use SINGER Oil and SINGER Lubricant!
Both are extra quality products especially pre
pared for sewing machines, and should always be
used in the care of your 401.
X
Clean the machine periodically as instructed on
page 84.
Apply a drop of oil to each place indicated.
Remove screws A and lift off arm top cover.
Apply a small amount of lubricant to the gears
as shown.
A tube of this lubricant can be purchased at your
Singer Sewing Centre.
Never apply Oil to these gears.
87
Swing face plate to left and oil the places indi
cated.
Open slide plate and apply a drop of oil to the
hook raceway as indicated.
Close slide plate, replace arm top cover and
close face plate.
