SINGER W811 - Manual (Page 8)

CHANGING THE BOBBIN
TO REMOVE THE BOBBIN FROM BOBBIN CASE:
• Raise needle bar to its highest position. Bobbin case cannot be
removed when needle bar is at low position.
• Open shuttle race cover, pull bobbin case latch with two fingers and
remove bobbin case as shown above.
• Remove bobbin from bobbin case by releasing latch.
Re(
anc
Th(
Th(
Sei
Mo
Ret
TO ATTACH THE BOBBIN CASE:
• Pull thread at least 3 inches from bobbin.
• Thread bobbin as shown on page) 7 ).
• Making sure that needle bar is at its highest position, insert bobbin
case into shuttle race by holding bobbin case latch. Make sure bob
bin case finger is inside shuttle notch. Press bobbin case into shuttle
as far as possible until latch catches on center post of the shuttle.
