SINGER W1776 - Manual (Page 48)

INSTALLING SEWING HEAD IN PORTABLE CASE
47
Please read these important instructions which
were written to aid you in placing your new
sewing machine in its portable case.
First, remove the foot control which is fastened
inside the base to avoid damage in shipping.
After unpacking the sewing machine unit, being
certain to take out the instruction book, guarantee
and accessory box, lay the unit face down on a
table. You will see two clamping screws A
entering head hinge holes B on the underside of
the back.
On the base you will find two head hinges C
which will fit into holes B. Lower the base onto
the sewing machine fitting hinges C into holes B.
Tighten screws A securely with a screw driver.
To make the electrical connection draw the
two wires through the slot in the partition of
the base.
Plug the cord labeled Motor” into the recepta­
cle marked“Motor" on the block attached to
the outer section of the base. Then insert the other
cord into the Light" receptacle.
Place the foot control on the floor, insert plug
into a wall outlet ( 1 1 0 - 1 1 5 volts) and you are ready
to sew. But first read the instruction book to becrime
familiar with the threading of the machine,
lension adjustments and all the other features
designed to make sewing a pleasure.
PORTABLE BASE
UNDER StDE or
MACHINE
PASS
MOTOR-LIGHT
LEADS THROUGH
SLOT IN
PARTITICI
lOTOR-LIGHT
“ PLUGS
MOTOR-LIGHT
BLOCK
