16 NUMERICAL LIST OF PARTS
No. Plate Name
596J 22583 Feed Doq Screw
624AL 22585 Needle Bar Lever Hinge Pin Bushing (bark) Set Screw
624AL 22585 Presser Bar Lifting Bracket Guide Set Screw
624AL 22586 Tension (upper thread) Releasing Shaft Crank Set Screw
for 54047
647E 22581 Needle Bar Lever Connecting Rod Cap (upper) Screw
for 59603 ........................................... ..........................................
665J 22583 Presser Foot Plate Hinge Stud Position Screw for 59649
and 59690 .............................
840E 22590 Machine Base Screw for 59698
882AL 22582 Feed Bar Hinge Pin Bushing (left) Set Screw for 59669
882AL 22582 Feed Bar Hinge Pin Bushing (right) Set Screw for 59669
882AL 22582 Feed Lifting Eccentric Connection Bar Set Screw for
59667 .
904AL 22586 Thread (under) Take-up Staple Set Screw for 59281 ........................
lOllF 22583 Throat Plate Screw
1072F 22585 Needle Set Screw for 59683
1143AL 22582 Looper Carrier Shaft Crank Clamping Screw for 59227
1143AL 22585 Presser Bar Lifting Bracket Set Screw for 59505
H49AL 22584 Throat Plate Packing (left) Screw
1149AL 22584 Throat Plate Packing (right) Screw
1I86E 22582 Looper Carrier Driver Clamping Screw for 59224
1247C 22590 Machine Bose Oil Drain Jar Clamp Lever Hinge Screw
for 131268
1299AL 22581 Needle Bor Lever Connecting Rod Eccentric Position Screw
for 59636
1317D 22586 Pressure Regulating Thumb Screw
1354C 22581 Machine Driving Pulley Position Screw for 59686
1423J 22581 Arm Side Cover Screw
1423W 22586 Thread (under) Eyelet Screw
I509J 22589 Knee Lifter Rock Shaft Knee Arm Lock Nut for 16646
1547J 22586 Pressure Regulating Thumb Screw Lock Nut
1547J 22586 Tension (upper thread) Releasing Shaft Stop Screw Nut
1602E 22584 Looper Cover Screw Bushing for 59663
2089 22581 Needle Bar Lever Connecting Rod Oil Pad Pin for 59603
2102 22586 Tension (under thread) Disc....................................................
2102 22586 Tension (upper thread) Disc
2764 22589 Knee Lifter Rock Shaft Hanger (back) with two wood
screws 1 in. No. 10, for 32135
2766 22589 Knee Lifter Rock Shaft Knee Arm Hub with 356C, for
16647
2767 22589 Knee Lifter Rock Shaft Knee Arm Plate with 356C, for
16647..............
2770 22589 Knee Lifter Rock Shaft Spring Adjusting Dog with
140219C, for 32135 . ....................................................................
2770 22589 Knee Lifter Rock Shaft Stop Dog with 140219C, for 32135
4822 22588 Wrench for 1547 (Accessories) ....................................................
4879 22589 Foot Lifter Chain Connecting Link for 4885
4881 22589 Foot Lifter Treadle for 4885 .....................................
4882 22589 Foot Lifter Treadle Shaft for 4885 .....................................................
4883 22589 Foot Lifter Treadle Spring for 4885.....................................................
4884 22589 Foot Lifter Treadle Stand for 4885
4885 22589 Foot Lifter Treadle complete, Nos. 4879, 4881, 4882,
4883, 4884 and two wood screws 1 in. No. 16
6055 22590 Machine Base Bolt Nut Washer for 59698
6337 22589 Knee Lifter Rock Shaft Lifting Bracket with two 356C,
for 32135.......................................
6338 22589 Knee Lifter Rock Shaft Lifting Bracket Hook for 32135
7071 22581 Feed Eccentric Clamping Washer for 59495
7071 22584 Hemmer Plate Screw Washer for 121543
7071 22584 Hemmer Screw Washer
7124 22589 Knee Lifter Rock Shaft for 32135
8282 22587 Presser Foot Yielding Heel Connection Spring (lower)
for 59690..............................
NUMERICAL LIST OF PARTS 17
No. Plate Name
8908 22588 Wrench (Accessories)
10107 22585 Needle Bar Thread Retainer Spring tor 59395
12002 22582 Feed Eccentric Connection Oil Wick Retaining Pin for
59216 ..................................................................................
13351 22589 Foot Lifter Chain, 46 in. to 55 in. long, with 56864 and
56865 .............................................. .................................
NOTE: When ordering No. 13351, state length required.
16128 22589 Knee Lifter Rock Shaft Hanger (front) with two wood
screws 1 in. No. 10, for 32135
16646 22589 Knee Lifter Rock Shaft Knee Arm with 1509J, for 16647
16647 Knee Lifter Rock Shaft Knee Arm complete, for 32135,
Nos. 2766, 2767 and 16646
17718 22585 Needle Bar Thread Retainer Bracket Screw Washer
19079 22588 Wrench (Accessories)
26026 22588 Screw Driver (large) Accessories .......................................................
26485 22588 Screw Driver (small) Accessories
27739 23289 Thread Unwinder Thread Cone (wood) for large cones
NOTE: No. 27739 is used with, but not included in 225258.
32040 22589 Knee Lifter Chain, 12-3/4 in. long, with 56864 and
56865,for 59682
32134 22589 Knee Lifter Rock Shaft Spring for 32135
32135 22589 Knee Lifter Rock Shaft complete, for 59682, Nos. 2764,
6337, 6338, 7124, 16128, 16647, 32134 and three
2770 ................................................................................
32572 22586 Tension (upper thread) Releasing Disc
36006 22590 Machine Base Cover Friction Washer for 59698
39443 22583 Presser Foot Yielding Heel Connection Spring for 59649
39443 22587 Presser Foot Yielding Heel Connection Spring (upper) for
59690
40247 22585 Needle Bar Connecting Link Hinge Pin (lower) for 59684
40247 22585 Needle Bar Connecting Link Hinge Pin (upper) for
59684........................................ .....................................................
42077 22581 Needle Bar Lever Connecting Rod Guide
42253 22585 Presser Bor Bushing (upper) ...............................................................
42483 22585 Needle Bar Thread Retainer Disc for 59395. . ...................................
42727 22581 Feed Lifting Eccentric Position Pin.....................................................
50014AL 22585 Thread (upper) Eyelet (side of orm) Set Screw
50138E 22585 Presser Bar Lifter Stop Screw
50150AL 22581 Feed Lifting Eccentric Set Screw for 59513
50300E 22584 Looper Cover Lock Stud Spring Cap Screw
50326C 22586 Tension (under thread) Screw Stud for 59539 ....................................
50326C 22586 Tension (upper thread) Screw Stud for 59539.....................................
50328C 22581 Feed Regulating Screw for 59495 ................
50395AL 22582 Looper Set Screw for 59381 .....................................................
50554AI 22581 Arm Rotary Shaft Bushing (back) Set Screw .....................................
50554AL 22581 Arm Rotary Shaft Bushing (intermediate) Set Screw..........................
51061AL 22581 Feed Eccentric Body Set Screw for 59495
51081E 22590 Machine Base Bolt with 51581E, to fasten base to table,
for 59698 .........................................................................................
51192E 22586 Tension (upper thread) Bracket Screw................................................
51407AL 22585 Needle Bar Lever Connecting Rod Ball Stud Set Screw
for 59471 .................................................. ............ ........... .............
51570C 22586 Tension (under thread) Regulating Thumb Nut for 59539. ..
51570C 22586 Tension (upper thread) Regulating Thumb Nut for 59539 .
51581E 22590 Machine Base Bolt Nut for 51081 E.......................................... ....... .
51810 22585 Presser Bar Spring Roller and Stud for 59505 ...................................
51811 22585 Slack Thread Regulator Holder Crank Roller and Stud
for 59505.................... ...................................................................
51815 22585 Presser Bar Lifter Roller and Stud for 59505 ....................................
52045 22581 Arm Rotary Shaft Bushing (back) Packing (wick) for
59610
52045 22581 Arm Rotary Shaft Bushing (front) Packing (wick) for 59524.
52045 22581 Arm Rotary Shoft Bushing (intermediate) Packing (wick)
