20 NUMERICAL LIST OF PARTS NUMERICAL LIST OF PARTS 21
No. Plate Name No. Plate
59667 22582 Feed Bar with two each 458AL and 882AL, for 59668 131266 22590
59668 Feed Bar 59667 with 59670 and 59671 131267 22590
59669 22582 Feed Bar Carrier with two 882AL and four 449AL, for 131268 22590
59670
59670 Feed Bar Carrier 59669 with 59617 and 59618, for
59668....................- ............................ - 131696 22586
59671 22582 Feed Bar Hinge Pin for 59668................. 131696 22586
59672 22585 Needle Bar Connecting Bracket with 175E and 460AL, 131961 22590
for 59684...................... ..................... ............................... 131962 22590
59673 22582 Needle Guard (movable)..................................................................... 132555 22581
59674 22582 Needle Guard Clamp...........................................................................
59675 22586 Presser Bar Spring 139110 22582
59676 22586 Presser Bar Spring Block.................................................................. - 140050C 22586
59677 22585 Thread I jpper) Eyelet (side of arm) 140219C 22589
59678 22585 Thread (upper) Take-up with 460AL................................................... ,
59679 22586 Knee Lifter Lifting Lever for 59682 140219C 22589
59680 22586 Knee Lifter Lifting Lever Extension for 59682 150203 23289
59681 22586 Knee Lifter Lifting Lever Spring for 59682 200383C 23289
59682 Knee Lifter complete, Nos. 21D, 219J, 32040, 32135, 201018C 23289
59511, 59679, 59680, 59681 and two 190J 201528X 23289
59683 22585 Needle Bar (hollow) with 1072F.......................... 201696J 23289
59684 Needle Bar Lever 59471 with 59237, 59672 and two 225257 23289
40247.............................................................
59686 22581 Machine Driving Pulley, "У" belt groove (outside diom. 225258 23289
of belt groove 2.9 in.) with 424C, and 1354C
59687 22587 Feed Dog, 11 teeth (6 teeth to the inch) for 59691, for
heavy overall work
59688 22587 Presser Foot Yielding Heel for 59690 225322 23289
59689 22587 Presser Foot Yielding Heel Connection with 62527, for 225324 23289
59690 .. .......................................................................................
59690 22587 Presser Foot (triple hinged) complete, for heavy overall 225326 23289
work. Nos. 8282, 39443, 59645, 59646, 59688, 59689 225388 23289
and two each 665J, 59652 and 62527. 225390 23289
59691 22587 Throat Plate for 59687, for heavy overall work................................... NOTE:
59697 22590 Machine Base for 59698 .. ....................................................... 225391 23289
59698 22590 Machine Base complete, for 59699, Nos. 100J, 36006, 259658 23289
59296, 59697, three each 840E, 59297 and four each 228692 23289
6055 and 51081E.......................................................... 228693 23289
59699 22590 Machine Base and Oil Drain Jar (swinging type) complete.
Nos. 59698 and 131268 .................................................. .............
62527 22583 Presser Foot Yielding Heel Connection Hinge Pin for
59649 and 59690
62527 22583 Presser Foot Yielding Heel Connection Spring Position
Pin for 59648 and 59689
62527 22583 Presser Foot Yielding Heel Hinge Pin for 59649 and
59690..............................................................................................
120341 22588 Tweezers (curved) Accessories................. ........................................
120344 22588 Oiler (copper plated) with 120345 (Accessories)................................
120345 22588 Oiler Spout, 4-1/2 in. long, for 120344 ................... ...........................
121543 22584 Hemmer on Shank (adjustable) complete. Nos. 121544,
121545 and two each 217J and 7071 — ......................
121544 22584 Hemmer on Shank for 121543............................................................
121545 22584 Hemmer Plate for 121543--------- --------
128571 Arm Rotary Shaft Bushing (Intermediate) Oil Wick
(braided cotton) for 59613.............. ............... ......................... —
130337 Feed Eccentric Lubricating Pad (wood) for 59495
130901 22581 Feed Lifting Eccentric Connection Bar Oil Tube Oil Pad
(wick) for 59635 ............................ ...............
131188 22590 Machine Base Oil Drain Jar Clamp for 131217.................................. i
131189 22590 Machine Base Oil Drain Jar Clamp Lever for 131217.........................
131217 Machine Base Oil Drain Jar Clamp 131188 and 131189,
for 131268 .................... ..................... .....................................
131265 22590 Machine Base Oil Drain Jar Nipple (long) for 131268.........................
Name
Machine Base Oil Drain Jar Nipple (short) for 131268
Machine Base Oil Drain Jar Nipple Elbow for 131268
Machine Base Oil Drain Jar (swinging type) complete,
for 59699, Nos. 131217, 131266, 131961, 131962
and two each 1247C, 131265 and 131267....................................
Tension (under thread) Thread Guide................................................
Tension (upper thread) Threod Guide...............................................
Machine Base Oil Drain Jar (glass) for 131268
Machine Base Oil Drain Jar Cap for 131268
Arm Side Cover Oil Tube Oil Pad (braided cotton) for
59629
Feed Eccentric Connection Oil Wick for 59216.................................
Thread (under) Take-up Stripper Bracket Screw...............................
Knee Lifter Rock Shaft Spring Adjusting Dog Set Screw
for 2770 ................ ............. .........
Knee Lifter Rock Shaft Stop Dog Set Screw for 2770 ......................
Threod Unwinder Spool Rest Cushion (felt) for 225258.....................
Thread Unwinder Spool Rest Rod Set Screw for 259658..
Thread Unwinder Spool Rest Set Screw for 225257..........................
Thread Unwinder Spool Pin Nut for 225257.......................................
Thread Unwinder Thread Guide Lock Nut for 225258.......................
Thread Unwinder Spool Rest with 201018C and two each
201528X, 228692 and 228693, for 225258
Thread Unwinder complete, for two spools or two large
cones of thread. Nos. 201696J, 225257, 225324,
225326, 225388, 259658, two each 150203, 225391
and three wood screws 7/8 in. No. 12 F.H.....................................
Thread Unwinder Thread Guide Rod Washer for 225324
Thread Unwinder Thread Guide Rod with 208AL and
225322, for 225258.....................
Thread Unwinder Thread Guide Position Cup for 225258...
Thread Unwinder Spool Rest Rod for 225258
Thread Unwinder Thread Cone Holder, for inverted cones
No. 225390 is used with, but not included in 225258.
Thread Unwinder Thread Guide for 225258.......................................
Thread Unwinder Spool Stand with 200383C, for 225258...
Thread Unwinder Spool Pin for 225257.............................................
Thread Unwinder Spool Pin Washer for 225257................................
