12
ACCESSORIES
No. Plate Name
120344 22588 Oiler (copper plated) with 120345
120345 22588 Oiler Spout, 4-1/2 in. long.....................
2602Ô 22588 Screw Driver (large).......................
26485 22588 Screw Driver (small).............................
120341 22588 Tweezers (curved).................................
4822 22588 Wrench for 1547..................... ............
8908 22588 Wrench................................................
19079 22588 Wrench................................................
FITTINGS
FOR HEAVY OVERALL WORK
59687 22587 Feed Dog, 11 teeth (6 teeth to the inch)
59645 22587 Presser Foot Plate.........................
59652 22587 Presser Foot Plote Hinge Stud (2)
665J 22587 Presser Foot Plote Hinge Stud Position Screw (2) .........................
59646 22587 Presser Foot Shank........................................................................
59688 22587 Presser Foot Yielding Heel....................................
59689 22587 Presser Foot Yielding Heel Connection with 62527
62527 22587 Presser Foot Yielding Heel Connection Hinge Pin
8282 22587 Presser Foot Yielding Heel Connection Spring (lower)
39443 22587 Presser Foot Yielding Heel Connection Spring (upper)...................
62527 22587 Presser Foot Yielding Heel Connection Spring Position Pin
62527 22587 Presser Foot Yielding Heel Hinge Pin..............................................
59690 22587 Presser Foot (triple hinged) complete, Nos. 8282, 39443,
59645, 59646, 59688, 59689 and two each 665J,
59652 and 62527...................................................... ..................
59691 22587 Throat Plate....................................................................................
FOOT LIFTER PARTS
22589 Chain, 46 in. to 55 in. long, with 56864 and 56865 13351
NOTE: When ordering No. 13351, state length required.
4879 22589 Chain Connecting Link................ .
56864 22589 Chain Hook (large)
56865 22589 Chain Hook (small)...............................................................................
4881 22589 Treadle.................................................................................................
4882 22589 Treadle Shaft ...................... ......... . ............................
4883 22589 Treadle Spring...........................
4884 22589 Treadle Stand.......... .
4885 22589 Treadle complete. Nos. 4879, 4881, 4882, 4883, 4884 and
two wood screws 1 in. No. 16......................................................
HEMMER ON SHANK
(Adjustable)
121544 22584 Hemmer on Shank........... ................... ............. ............. -............
121545 22584 Hemmer Plate ................................ .......................... -.........................-
217J 22584 Hemmer Plate Screw (2). .......................... .............. ........................ .
7071 22584 Hemmer Plate Screw Washer (2). . .. ...........................—.............
121543 22584 Hemmer on Shank (adjustable) complete, Nos. 121544,
121545 and two each 217J and 7071......................................
190J 22584 Hemmer Screw (2) ................... ..................................................
7071 22584 Hemmer Screw Washer (2).........................................................
13
KNEE LIFTER PARTS
No. Plate
32040 22589
56864 22589
56865 22589
59679 22586
59680 22586
190J 22586
21D 22586
59681 22586
59511 22586
219J 22586
7124 22589
2764 22589
16128 22589
16646
16647 22589
2766 22589
356C 22589
1509J 22589
2767 22589
356C 22589
6337 22589
6338 22589
356C 22589
356C 22589
32134 22589
2770 22589
140219C 22589
2770 22589
140219C 22589
32135 22589
59682
Name
Chain, 12*3/4 In. long, with 56864 and 56865 _____
Chain Hook (large).....................................................................
Cha in Hook (small)....................................................................
Lifting Lever..............................................................................
Lifting Lever Extension...............................................................
Lifting Lever Extension Screw (2)...............................................
Lifting Lever Hinge Screw...........................................................
Lifting Lever Spring....................................................................
Lifting Lever Stop.......................................................................
Lifting Lever Stop Screw.............................................................
Rock Shaft .................................... . .......... . . ___________
Rock Shaft Hanger (back) with two wood screws 1 in.
No. 10 ................... ............. . . ___________
Rock Shaft Hanger (front) with two wood screws 1 in.
No. 10 ....................... ................................................... .......
Rock Shaft Knee Arm with 1509J .............. ..........
Rock Shaft Knee Arm complete, Nos. 2766, 2767 and
16646 .................... ..............................................................
Rock Shaft Knee Arm Hub with 356C . ....................................
Rock Shaft Knee Arm Hub Set Screw........................................
Rock Shaft Knee Arm Lock Nut.................................................
Rock Shaft Knee Arm Plate with 356C......................................
Rock Shaft Knee Arm Plate Set Screw.......................................
Rock Shaft Lifting Bracket with two 356C..................................
Rock Shaft Lifting Bracket Hook.................................................
Rock Shaft Lifting Bracket Hook Set Screw ..............................
Rock Shaft Lifting Bracket Set Screw.........................................
Rock Shaft Spring.......................................................................
Rock Shaft Spring Adjusting Dog with 140219C____________
Rock Shaft Spring Adjusting Dog Set Screw...............................
Rock Shaft Stop Dog with 140219C (2).................. ...................
Rock Shaft Stop Dog Set Screw (2)............................................
Rock Shaft complete. Nos. 2764, 6337, 6338, 7124,
16128, 16647, 32134, and three 2770 ..................................
Knee Lifter complete. Nos. 21D, 219J, 32040, 32135,
59511, 59679, 59680, 59681 ond two 190J...........................
MACHINE BASE
59697 22590
51081E 22590
51581E 22590
6055 22590
59296 22590
36006 22590
lOOJ 22590
840E 22590
59297 22590
59698 22590
59699 22590
Machine Bose.........................................................
Machine Base Bolt with 5158IE, to fasten base to table (4).
Machine Base Bolt Nut (4)......................................
Machine Base Bolt Nut Washer (4)......................................................
Machine Base Cover............................................................................
Machine Base Cover Friction Washer..................................................
Machine Base Cover Hinge Screw......................................................
Machine Base Screw (3)......................................................................
Machine Cushion (felt) (3)............................................... ...................
Machine Base complete, Nos. lOOJ, 36006, 59296,
59697, three each 840E, 59297 and four each 6055
and51081E............. . ..................... ............... . .......................... .
Machine Base and Oil Drain Jar (swinging type) complete,
Nos. 59698 and 131268..................................................................
