Paga
49
[
Section
English
LOWER TENSION
ADJUSTMENT
If your machine skips stitches
or loops stitches, it may
require a tension adjustment.
To check bobbin thread ten
sion, follow these steps;
(3)
Push latches of the shuttle
race cover to the outside,
as shown in figure ®.
(D Remove shuttle cover as
shown in figure ®.
@ Remove the shuttle as
shown in figure
@ Suspend bobbin, bobbin
case, and shuttle all
together by thread as
illustrated in figure ®.
When jerking the thread
slightly, all of them should
slide down with light resis
tance. If they do not slide
down with a slight jerk of
the thread, the bobbin
case tension is too tight. If
they slide down too easily,
the bobbin case tension is
too loose. See following
page for adjustment ot the
bobbin case. Once the
bobbin case is correclly
adjusted, it is easy to use
the upper tension to bal
ance
the
stitches
as
shown on page 12.
X Shuttle
y Bobbin ascrew using
small screwdriver^____
Español
AJUSTE DE TENSIÓN DE
LA BOBINA
Si la máquina pierde puntos o
hace nudos por el revés en la
costura no es problema de la
máquina, sino de la tensión.
Para verificar la tensión de la
bobina, se debe tomar ésta y
el cangrejo como se indica en
el dibujo, si la tensión es cor
recta se desplazarán lenta
mente.
Después ajustar la tensión
superior con los número 4, 5,
o 6.
® Girar los seguros hacia
afuera.
@ Quitar la tapa del cangrejo
(D
Quitar el cangrejo.
@ X Cancrejo
y Carrete y bobina
El cangrejo y la bobina se
desplazarán lentamente.
