1. Take-up
2. Pressure Control
3. Top Thread Guides
4. Stitch Pattern Window
[Model 426]
5. Stitch Pattern Selector
[Model 426]
.
6. Selector Release
[Model 426]
Blind Stitch Selector
[Model 415]
,
7. Creative Embroidery
Control
8. Bobbin Winder
9. :' Hand Wheel
10. Clutch nut
11. Stitch Width Control
12. Stretch Stitch Lever
13. Stitch Length Control
14. Reverse Push Button
S'
15. Feed Dog Height
Control •
16. Needle Plate
17. Feed Dog ,
18. Presser Foot
19. Slide Plate
20. Thumb Screw
21. Needle Clamp
22. Tension Clamp
23. Check spring
24. Thread Guard
[Model 426]
25. Light Switch
26. Face Cover
27. Bobbin Winder
Tension disc
28. Presser Foot Lever
29. Thread Cutter
30. Head Hinge Holes
31. Spool Pins
