10 PARTS FOR MACHINE NO. 115 1
NO. PLATE NAME
13801) 6306 Rotating Hook Bol)bin Case Tension
S])rlng Screw..................................................
55651 6306 Rotating Hook Bol)bin Case complete.
Nos. 592ii, 13801), 2975, 50093 f , 52313,
52364, 55626 and two 52342.........................
50150c 6306 Rulating Hook I’osition Screw...........................
55633 6306 “ “ Section...................................................
5015In 6306 “ “ “ Screw..................................................
4620 6301) “ “ Set Screw...............................................
55631 6301 “ “ Shaft.......................................................
55635 6306 “ “ “ Crank with 462 k
and 791 k .........................................................
791 к 6306 Rotating Hook Sliaft Crank Po.sition
Screw..............................................................
4G2 k : 6306 Rotating Hook Sliaft Crank Set Screw.. .
2102 6307 'J'plisioil Disc......................................................
1560U 6307 “ Regulating 4’luiml) Nut.............................
32572 6307 “ Releasing Disc...........................................
15238 0307 “ “ Pin...........................................................
5029lE 4918 “ Stud............................................................
15410 4918 “ “ Bushing...................................................
50292 b 4918 “ “ Set Screw................................................
13710 6307 “ Spring.........................................................
15395 4918 “ 'Idiread Guard............................................
26075 6307 'I'liread Gutter ami Holder..................................
55636 6300 “ 4'ake-ui) with 4-18c and
1293c..............................................................
1293c 6308 d'liread Take-U{) ('am Position Screw. . . .
448c 6302 “ “ “ Set Screw..............................................
15071 6305 “ “ I.ever with 1822......................................
79c 6305 “ “ “ Hinge Screw.........................................
1822 0305 “ “ “ Roller and (Stud...
55645 4018 “ “ ,S])ring.....................................................
15412 4918 “ “ “ Regulator..............................................
857 b 4918 “ “ “ “ Set Screw
15280 6303 Tliroat Plate for 55615........................................
691 a 6308 “ “ Serew.......................................................
11
MACHINE No. 115-2
FOR FAMILY USE, ROTARY HOOK, H. 0.
This Machine is the same as No. 115-1 with the addition
of the following:
HAND ATTACHMENT PARTS
NO. PLATE NAME BACH
*94002 4915 Body............................................................................
33647 4915 “ Bracket..........................................................
183 e 4916 “ “ Screw..............................................
80023 4915 Crank Handle (wood)...................................
94012 4915 “ “ Spindle...................................
8280 4916 “ Hinge Pin.....................................................
8435n 4915 “ Lever............................................................
8281 4916 “ Lock Pin......................................................
8282 4916 “ “ “ Spring......................................
94005 b ------- Crank complete. Nos. 8435 b , 80023 and
94012..............................................................
94006 b 4916 Driver........................................................................
33643 b -------- “ Finger..............................................,....................
94007 b 4916 “ “ 33643 b with 8390, 8391 and
94009..............................................................
80018 4916 Driver Finger Hinge Pin.............................................
94008
4916 “ “ Lock Pin.........................................
8388 4916 “ “ “ “ Spring.........................
94009 4916 “ “ Sheath (leather)........................
8390 4916 “ “ “ Plate. .. (.......................
8391 4916 “ “ “ Staple...........................
94010 4915 Gear with 8281 and 8^82........................................
94011 4915 “ Cover............................
211 a 4916 “ “ Screw..........................
SS380I) 4916 “ Screw Stud........................
80027 4916 Pinion......................................................................
80028 4916 “ Dowel Pin...................................... per 100
SS381I) 4916 “ Screw Stud..................................................
94001 b -------- Hand Attachment complete. Nos. 137 b ,
SS380 d , SS381 d , 8280, 8388, 33647,
80018, 80027; 80028, 94002, 94005 b to
94007 b , 94008, 94010, 94011 and two
each 183 e and 211 a ........................................
137 b 4916 Hand Attachment Screw..........................................
