28 TRIMMINGS FOR PORTABI.E CASE
NO. i'LATE NAMK
2822!) 6413 Handle Hinge Rivet............................................
87558 0413 “ Link............................................................
28231 6413 “ Stud............................................................
87550 — Handle complete, Nos. 28088, 28231,
87555, two each NN83j, 28229, 50289n
and 87558.......................................................
87342 6413 Machine Button with 84151 and wood
screw 1 in. No. 9 R. H. B...............................
84151 6413 Machine Button Washer (leather)......................
82i)4 2908 “ Hinge Connection.....................................
82!)5 2908 “ “ “ Hinge Pin.. .
50380c 0317 “ “ “ . Set Screw....
87571 0413 “ “ Head.......................................................
SS368n 6413 “ “ “ Screw...................................................
87572 6413 “ “ “ “ Wa.sher.............................................
87573 — Machine Hinge complete, Nos. SS368 b ,
8294, 8295, 87571 and 87572........................
28242 6413 Machine Rest Cushion (leather) with 5604
5004 6413 “ “ “ I’in......................................... per 100
OBSOLETE PARTS
NO. PLATK NAM К
649 e 6323 Arm Screw..........................................................
8300 6301 “ Side Cover, use 55513..................................
15283 6313 Bobbin Winder Adjusting Arm..........................
32600 6314 “ “ Stop Latch...............................................
,5006011 0313 “ “ “ “ Hinge Screw.
32607 6314 “ “ 'I'liread Guide...........................................
152!)3 6313 “ “ “ “ S p r i n g . . . .
*2813 — Face Plate...........................................................
2814 6300 “ “ 2813 with 2815...........................................
*2815 6307 “ “ Tension Seat................................................
.55610 — Face Plate complete. Nos. 248 a , 1338 e ,
1560n, 2814, 2826, 2827, 2830, 13710,
15238, 32572, 55637 and two 2102, use
55614........................ ■ ....................................
74 e 6302 Feed Regulator Hinge Screw..............................
28029 712 Latch...................................................................
28u30 712 “ Button (brass)..............................................
28032 2908 “ “ Hinge Pin...................................................
28033 712 “ Frame...........................................................
28037 712 Latch (brass) complete. Nos. 5604, 28029,
28030, 28032 to 28034 and 28200.................
39601 — Needle Bar Connecting Stud with 1341c.
1341c “ “ “ “ Set Screw...
OBSOLETE PARTS 29
NO. PLATE NAME
55627 6305 Rotating Hook Bobbin Case Delivery Eye
Thread Guard..................................................
55628 6305 Rotating Hook Bobbin Case Delivery Eye
Thread Guard Rivet........................... .............
55631 6305 Rotating Hook Bobbin Case Tension
Spring.............................................................
55632 6305 Rotating Hook Bobbin Case complete,
Nos. 592 e , 1380 d , 2975, 50093 f , 55626
to 55628 and 55631, use 55051......................
1338 e 6307 Tension Screw Stud.................................................
2826 6307 “ 'I'hread Guard.............................................
55637 6307 Thread Take-up Spring..............................................
2830 6307 “ “ “ Regulator......................
248 a 6307 “ “ “ “ S e t
Screw..............................................................
EACH
