rface
Fig- 8
S L O T
Fig. 9
TENSION SPRING
Fig. 10
ond,
and
as
ring
placing bobbin case in shuttle
n_,se needle bar to highest position, and slide cover plate
L 1 U 17 Fig 1) Hold the bobbin case latch, (D,
n between the thumb and forefinger of the left hand,
^'®,h at least three inches of thread running from the top of
r hobbin case to the right. Insert and center the bobbin
on the stud of the shuttle body, (C). Be sure the
Zbb>°case finger, (E),is opposite the shuttle race notch (A)
Press the bobbin case (B) into the shuttle as far as possible
t 1 latch catches on the center post of the shuttle. THEN
"Tlease the bobbin case latch, (D). Press bobbin case again
'o U»rh has been released to make sure the bobbin case
,S locked securely in place. Close the cover plate.
