11.
THREADING THE MACHINE
• THREADING DIAGRAM
* A color coded threading diagram is located inside
the looper cover for quick reference.
* Thread the machine in the order 0 to 0 as
shown.
* UNDERSTANDING THE COLOR CODE
* Left needle thread — Blue
@
* Right needle thread - Green 0
* Upper looper thread — Orange 0
* Lower looper thread — Yellow
@
* STITCH DIAGRAM
* Upper looper thread — Orange
0
* Lower looper thread — Yellow
0
* Left needle thread
— Blue
®
* Right needle thread
— Green
0
• TO THREAD THE MACHINE
CORRECTLY
(1) Threading the Upper Looper (Orange)
* Thread the upper looper as indicated ©
® •
3 THREADS
LEFT
RIGHT
NEEDLE NEEDLE
10
