CHANGING PRESSER FOOT
REPLACING PRESSER FOOT WITH SHANK
TO REMOVE-
• Lift toe of presser foot
until it snaps off shank.
• Take foot off machine.
JZy
TO REPLACE-
• Center new presser foot
under shank(1).
• Lower presser foot lifter.
• Press presser bar (2) down.
ATTACHING FEED COVER
Press tab (1) and (2) into holes on
needle plate.
• Loosen presser foot screw and
remove foot.
Hook new foot around presser bar.
Tighten screw.
11
—
