CLEANING AND OILING THE SHUTTLE
17
The stitch, forming mechanisin occasionally
becomes clogged with loose threads and lint.
This will interfere with the efficient operation
oi the machine. Cleaning and removal of the
lint will safeguard the performance. To remove
shuttle:
1. Turn the balance wheel until the needle
reaches its highest position. Tilt head
back on its hinges-
Remove bobbin case (A), Fig. 25.
Turn shuttle race cover clamps B down­
ward and pull hinged shuttle race cover,
C, down and remove shuttle D.
'
Clean the shuttle race, the shuttle, and
shuttle race cover by removing all threads
lint, etc. '
Apply a drop of oil with finger tip to outer edge of shuttle.
Pui tbe bobbin cse into sbnttle race, fitting tongue info notch E of race cover.
2
.
3.
4.
5.
2 .
3.
4.
5.
Fig. 25
............. ■ ■ ■ - ■ ■
