PLACING BOBBIN
CASE IN SHUTTLE
Raise needle bar to high.-
est position, and lift bing
ed
cover
plate. (See 12,
Fig.
1.)
-Hold
tbe
bob
bin case latch, (D^, Fig.
9
,
between
the
thumb
and
forefinger of the left hand
, ,
with at least three inches,
oi thread running from the top of the bobbin case
o the right. Insert and center the bobbin case on
the stud of the shuttle body, (C). Be sure the bob
bin case finger, (E), is opposite the shuttle race
notch,
(A).
Press
the
bobbin
case
(B)
into
the
shutde as far as possible until latch catches on the
center post of the shuttle. THEN release the bobbin
case latch, (D). Press bobbin case again after latch
has been released to make sure the bobbin case is
locked securely in place. Close the cover plate.
1
)
2
)
UPPER THREADING
(Fig.
lo)
Place spool of thread on spool pin.
Lead thread through upper thread' guide A on
back of face plate.
down and around tension discs B from back to
front.
