LEAI^IMQ AND LUBR!CAT3N
To keep your machine running smoothly ; it is necessary to clean using the brush from the ac
cessory box now and then.
This machine requires very little lubrication as the main components are made of special
materials.
Occassionally, lubricate only the points illustrated.
SPECIFICATION OF MACHINE
. i
Description
Specification
Number of threads
4 or 3
Number of needles
2 or 1
Sewing speed
Up to 1500 s.p.m
Stitch width
4-thread ................. 6mm
3-thread.................. 6mm or 4mm
Stitch length
l~5mm
Lift of presser foot
4.5mm
Needles
HA XI No. 11-14 or
130/705H No.75-90
Dimentions
285mm(W) x 285mm(D) x 291mm (H)
W eight
7kg(approx. 15 lbs.)
^ -
