THREADING UPPER THREAD

Threading the thread

horn A to i as shown

DRAWING UP BOBBIN THREAD

1. Hold upper thread with left

hand, turn the hand wheel

slowly towards you until the

needle goes down and comes

up.

Then

stop

the

hand

wheel when the takeup (ever

is at its highest position.

Lightly draw up the upper

thread will be brought up in a

loop.

2. Pull out txjth threads and

place them together under

presser foot to the rear of

machine.

CHANGING SEWING DIRECTIONS

Twin needle threading

1. Lower needle down into tabiic and

raise

presser

foot, pivot

the

fabric

arourid the needle to change direction

Put down presser foot and

start to sew.

as desired.

10 ■
