Ducting Infcxmotion
The ventilation system is designed to capture both
cooking fumes and smoke while grilling. If the system
does not, these are some ducting installation situations
to check:
• 6" diameter round or 3H" x 10" rectangular duct
ing should be used. Note: 5" diameter round
ducting may be used if the duct length is 10' or less.
•
No more than three 90® elbows should be used.
Distance between elbows should be at least 18".
• There should be a minimum clearance of 6" for
cooktop installed near a side wall.
If there is not an obvious improper installation, there
may be a concealed problem such as a pinched joint,
obstruction in the pipe, etc. Installation is the respon
sibility of the installer and questions should be ad
dressed first by the installer. The installer should very
carefully check the ducting installation instructions.
Recommended Kenmore wall cap should be used.
Make sure damper moves freely when ventilation
system is operating.
