Repair Parts
12 & 16-GALLON WET/DRY VACS
Always order by Part Number - Not by Key Number
Model Numbers 113.177000 & 113.177020 _____
■ “ WARNING "
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a doubie-insu-
lated Wet/Dry Vac requires extreme care and knowledge of the system, and
should be done only by qualified service personnel. Replacement parts for a
double-insulated Wet/Dry Vac must be identical to the parts they replace. Your
double-insulated Wet/Dry Vac is marked with the words "DOUBLE INSULA! ED"
and the symbol
anees.
□
(square within a square) may also be marked on the appli
Key
No,
12 Gallon
113.177020
Part No.
16 Gallon
113.177000
Part No. Description
1 73180 73180 Toggle Switch
2 818806 818806 Motor Cover
3 818802-1 818802-7 Motor (Includes Key No’s 8,9,10 &11)
4 820506 820506 Motor Gasket
5 STD611007 STD6110O7 * Screw, Pan Hd. Ty “AB" 10x3/4
6 820505 820505 Coilector
7 818793 818793 Lid Gasket
8 818961 818961 Spacer
9 818413-2 818413-2 Blower Wheel
10 15534-1 15534-1 Washer
11 73352 73352 Nut, Hex Flange 1/4-20
12 819451-4 819450-4 Lid
13 9-17816 9-17816 t Fitter (Red Stripe)
14 73317 73317 Filter Plate
15 73316 73316 Filter Nut
16 9-16931 9-16931 t Caster Foot with Storage
17 73102 73102 Caster
18 73185 73185 Drain Cap
19 9-16922 9-16922 t Utility Nozzle
20 73324 73324 Hose Swivel
21 9-17820 9-17820 t Hose (Includes Key No. 20)
22 73362 73362 Filter Cage
23 73349 73349 Float
24 814567 009544-3 Dust Drum
- SP5686 SP5686 Owners Manual
t Slock Hem - May Be Secured Through The Hardware Department Of Most Sears
Retail Stores
* Standard Hardware Item - May Be Purchased Locally.
10
