REMOVABLE PARTS
REPLACING THE OVEN
LÍGHTBÜLB
OVENDOOR
SOCKET
TO REMOVE THE COVER:
1, Disconnect electrical power to the oven at
the main circuit breaker or fuse box.
2. Hold your hand under cover and firmly
push back the bail wire, until it dears and
releases the bulb cover
REPLACE THE LIGHT BULB:
Unscrew the light bulb and replace it with a
40-watt home appliance bulb.
TO REPLACE COVER:
1, Place the bulb cover into the groove of the
bulb socket.
2, Pull the bait wire forward until it snaps into
the indentation on top of the bulb cover
3, Reconnectthe electrical power to the oven
A
Do not touch a hot oven light
bait. Do not touch a bulb with
wet hands or wet cloth.
Never touch the electrically
live collar on the bulb when
removing or replacing the
bulb. Do not remove any
screws.
TO REMOVE:
Open the door to the
broil stop position.
Grasp the door on each
side and lift up and off
the hinges. DO NOT
LIFT THE DOOR BY
THE HANDLE,
When the door is
removed and the hinge
arms are in the broil stop
position, do not bump
into the hinge arms.
They could snap back
and cause injury to
hands and damage the porcelain finish
of the front frame. Cover the hinge
arms with empty paper towel roiis or
towels while working in the oven area.
TO REPLACE:
Remove the paper towel
rolls or towels. Make sure
the hinges are still in the
broil stop position. Grasp
the door on each side. Lift
the door over each hinge.
Line the slots at the
bottom of the door with the
hinges. Slide the door
down over the hinges as
far as it will go
20
