SEARS CRAFTSMAN 5 H.P. CHIPPE R-SHREDDER MODEL NO. 247.795850
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1
742-0571
Blade
38
736-0119
L-Wash. 5/16" I.D.*
2
710-1254
Hex Patch Bolt 3/8-24 <
39
710-3008
Hex Bolt5/16-18
X.
75" Lg.
2.25" Lg. (Gr.
8)
(Gr. 5)
4
736-0217
L-Wash. 3/8" I.D. H.D.
40
710-0442
Hex Bolt 5/16-18x1.5" Lg.*
5
736-0247
FI-Wash. .406" I.D. x 1 25"
41
681-0004
Flail Housing Ass’y.—L.H.
O.D. Hdn.
42
781-0474A
Flail Housing Ass’y.—R.H.
6
11459B
Flail
43
735-0639
Spark Plug Boot
7
711-0564
Flail Spacer
44
143.955003
Engine—Model 143.955003
8
711-0833B
Clevis Pin .496" Dia.
45
747-0531A
Release Bar
9
711-0834A
Flail Spacer w/.160" Dia. Hole
46
732-0546
Torsion Spring 1.06" Lg.
10
715-0249
Spring Roll Pin 1.12" L
3.
47
712-0429
Elastic Lock Nut 5/16-18 Thd.
11
736-0192
FI-Wash. .531" I.D.
X.
94" O.D.
48
710-0601
Hex Wash. Hd. Self-Tap Scr.
12
681-0030
Impeller Ass’y- Comp
.1
5/16-18
X.
75" Lg.
13
781-0490
Chipper Blade
49
11480
Stop Washer
14
710-1054
Flat Hd. Scr. 5/16-24 x .75" Lg.
50
736-0264
FI-Wash. 5/16" I.D.
15
712-0411
Hex Top L-Nut 5/16-24 (Gr. 5)
51
710-0542
Hex Bolt 5/16-18x8.38" Lg.
16
736-0119
L-Wash. 5/16" I.D.*
52
781-0487B
Back-Up Plate
17
710-0825
Hex Bolt 1/4-20x3.75' Lg.*
53
16522B
Inlet Guide Ass’y.
18
736-0142
FI-Wash. .281" I.D. x.iO" O.D.
54
781-0494
Pivot Hopper Hood
19
750-0793
Chute Hinge Spacer 1.36" Lg.
55
16524B
Upper Guide Ass’y.
20
711-0835
Clevis Pin .5" Dia. x 4.(i2" Lg.
56
710-0286
Truss Mach. Scr. 1/4-20 x .5"
22
712-0291
Hex Ctr. L-Nut 1/4-20 I hd.
Lg.
23
714-3010
Cotter Pin
57
712-0107
Hex L-Nut 1/4-20 Thd.
24
781-0457
Shredder Screen
58
11461B
Upper Leaf Ramp Section
25
714-0149B
Internal Cotter Pin 3/8" Dia.
59
726-0214
Push Cap 5/8" Dia. Rod
26
781-0480
Chute Deflector Ass’y-
61
750-0786
Spacer .64" I.D. x .38" Lg.
27
712-3010
Hex Nut 5/16-18 Thd. (Gr. 5)
62
738-0814
Shredder Axle
28
736-0242
Bell-Wash. .345" I.D. x .
88"
63
734-1600
Wheel Ass’y. Comp.
29
720-0170
Hand Knob
75
732-0629
Torsion Spring
30
747-0744A
Chipper Door Rod
76
747-0747
Hopper Door Rod
31
732-0542
Torsion Spring 1.14" Lg.
77
781-0492
Hopper—Pivot Door
32
781-0489
Chipper Door
78
781-0493
Hopper Lockout Brkt.
33
781-0475
Chipper Chute Ass’y.
79
726-0106
Cap Speed Nut 1/4" Rod
34
736-0170
Spec. L-Wash. 5/16" LID.
—
764-0199A
Bag (Not Shown)
35
712-3010
Hex Nut 5/16-18 Thd. (Gr. 5)
—
723-0400
Safety Glasses (Not Shown)
36
781-051OA
Shredder Frame
—
770-8901K
Owner’s Manual
37
710-0157
Hex Bolt 5/16-24
X
.75' Lg.
tincl. Ref. 1,
6, 7, 8, 9, 10, 11, 12, 13, 14
‘Common Hardware—May Be Purchased Locally.
NOTE: Specifications subject to change without
notice or obligation.
