PARTS UST FOR SEARS HUMIDIFIER
MODEL NO. 758.148080
Key
No.
Part
No. Description
1 821848 Stationary Lid
2 821846 Hinged Access Lid
3 821847 Housing
4 822120 Caster
5 STD601005 * Screw, Pan Hd. Type T' 10-32 x 1/2
6 817235-4 Knob, Humidity
7 817235-3 Knob, Contrd
8 821908-1 •Control (Includes Key No. 6 and 7)
9 817878 Tie Ring
10 817380 Switch Actuator
11 29433 Screw, Pan Hd. Type "AB" 8x5/8
12 821851 Label, Control
13 STD541408 * Lock Nut, 8-32
14 STD551010 * Washer. 13/64x3/4x1/16
15 V27217 Grommet
16 817964 Spacer
17 817197-1 Motor Housing
18 817966 Grommet
19 817237 Airseal Gasket
20 818087-1 • Motor
21 V30187 Fan Blade
22 816133 Clamp
23 803144-2 Push Nut. 5/16
24 817196 Filter Housing
25 32-14910 t Evaporation Filter
26 817195 Filter Float
— SP5660 ' Owners Manual (Not Illustrated)
• Any attempt to repair this control assembly or motor may create a HAZARD unless repair
is done by a qualified service technician. This assembly is factory aligned. Repair service
is available at your nearest Sears store.
t Stock Item - May be secured through the Plumbing and Heating Department of most
Sears Retail Stores.
* Standard Hqirdware Item - May be purchased locally.
