SERVICE AND ADJUSTMENTS

TO REPLACE MOWER BLADE DRIVE BELT

(See Fig. 26)

The mower blade drive belt may be replaced without tools.

Park the tractor on level surface. Engage parking brake.

BELT REMOVAL -

•

Remove mower from tractor (See “TO REMOVE
MOWER” in this section of this manual).

•

Work belt off both mandrel pulleys and idler pulleys.

•

Pull belt away from mower.

BELT INSTALLATION -

•

Install new belt in reverse order of removal.

•

Make sure belt is in all pulley grooves and inside all belt

guides.

•

Install mower in reverse order of removal instructions.

IDLER
PULLEYS

MANDREL
PULLEY

FIG. 26

TO ADJUST BRAKE (See Fig. 27)

Your tractor is equipped with an adjustable brake system
which is mounted on the right side of the transaxle.

If tractor requires more than six (6) feet stopping distance

at high speed in highest gear, then brake must be adjusted.

•

Depress clutch/brake pedal and engage parking brake.

•

Measure distance between brake operating arm and

nut "A" on brake rod.

•

If distance is other than 1-3/4", loosen jam nut and turn

nut “A" until distance becomes 1 -3/4". Retighten jam
nut against nut "A".

•

Road test tractor for proper stopping distance as stated

above. Readjust if necessary. If stopping distance is
still greater than six (6) feet in highest gear, further
maintenance is necessary. Contact your nearest au

thorized service center.
