SEARS CRAFTSMAN 8 H.P. CHIPPER-SHREDDER MODEL NO. 247.780890
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1
13431
Blade
40
710-0380
Hex Bolt 5/16-18
X
1.75" Lg.*
2
710-0818
Hex Patch Bolt 3/8-24 x 2" Lg.
41 781-0473
Flail Housing Ass’y.—L.H.
(Gr. 8)
42 781-0474
Flail Housing Ass’y.—R.H.
3
714-0114
Sq. Key 1/4 x 2.0" Lg.
43 735-0639
Spark Plug Boot
4
736-0217
L-Wash. 3/8" I.D. H.D.
44
HM80-155426L
Engine—Tec. HM80-155426L
5
736-0247
FI-Wash. .406" I.D. x 1.25"
45 747-0531A
Release Bar
O.D. Hdn.
46 742-0546
Torsion Spring 1.06" Lg.
6
11459B
Flail
47 712-0429
Elastic Lock Nut 5/16-18 Thd.
7
711-0564
Flail Spacer
48 710-0601
Hex Wash. Hd. Self-Tap Scr.
8
711-0833A
Clevis Pin .496" Dia.
5/16-18
X
.75" Lg.
9
711-0834
Flail Spacer w/.160" Dia. Hole
49
11480
Stop Washer
10
715-0249
Spring Roll Pin 1.12" Lg.
50 736-0264
FI-Wash. 5/16" I.D.
11
736-0192
FI-Wash. .531" I.D. x .94" O.D.
51 710-0542
Hex Bolt 5/16-18
X
8.38" Lg.
12
781-0484
Impeller Ass’y.
52 781-0487A
Back-Up Plate
13
781-0490
Chipper Blade
53
16522A
Inlet Guide Ass’y.
14
710-1054
Fl9t Hd. Scr. 5/16-24 x .75" Lg.
54 781-0494
Pivot Hopper Hood
15
712-0411
Hex Top L-Nut 5/16-24 (Gr. 5)
55
16524B
Upper Guide Ass’y.
16
736-0119
L-Wash. 5/16" I.D.*
56 710-0286
Truss Mach. Scr. 1/4-20 x .5"
17
710-1058
Hex Bolt 1/4-20 x 4.0" Lg.*
Lg-
18
736-0142
FI-Wash. .281" I.D. x .50" O.D.
57 712-0107
Hex L-Nut 1/4-20 Thd.
19
750-0793
Chute Hinge Spacer 1.66" Lg.
58
11461B
Upper Leaf Ramp Section
20
711-0835
Clevis Pin .5" Dia. x 4.62" Lg.
59 726-0214
Push Cap 5/8" Dia. Rod
21
736-0329
L-Wash. 1/4" I.D.*
60 736-0187
FI-Wash. .64" I.D.
X
1.24"
22
712-0287
Hex Nut 1/4-20 Thd.*
61 750-0786
Spacer .64" I.D. x .38" Lg.
23
714-3010
Cotter Pin
62 738-0813
Shredder Axle
24
781-0457
Shredder Screen
63 734-1597
Wheel Ass’y. Comp.
25
714-0149
Internal Cotter Pin 3/8" Dia.
734-1598
Tire Only
26
781-0480
Chute Deflector Ass’y-
64 732-0629
Torsion Spring
27
712-3010
Hex Nut 5/16-18 Thd. (Gr. 5)
65 747-0747
Hopper Door Rod
28
736-0242
Bell-Wash. .345" I.D. x .88"
66 781-0492
Hopper—Pivot Door
29
720-0170
Hand Knob
67 781-0493
Hopper Lockout Brkt.
30
747-0744A
Chipper Door Rod
68 726-0106
Cap Speed Nut Va" Rod
31
732-0542
Torsion Spring 1.14" Lg.
69 734-1455
Rim Only
32
781-0489
Chipper Door
76 741-0487
Flange Brg. .632" I.D.
33
781-0475
Chipper Chute Ass’y.
77 737-0280
Grease Fitting
34
736-0170
Spec. L-Wash. 5/16" I.D.
78 734-0225
Air Valve
35
712-3010
Hex Nut 5/16-18 Thd. (Gr. 5)
—
764-0199A
Bag (Not Shown)
36
781-0510
Shredder Frame
—
723-0400
Safety Glasses (Not Shown)
37
710-0157
Hex Bolt 5/16-24 x .75" Lg.
—
770-7387F
Owner’s Manual
38
736-0119
L-Wash. 5/16" I.D.*
39
710-3008
Hex Bolt 5/16-18
X
.75" Lg.
(Gr. 5)
* Common Hardware May Be Purchased Locally.
