SEARS CRAFTSMAN 9 H.P. ENGINE MODEL NO. 143.959001
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
287 29752 Nut & Lock Washer, 1/4-28 342 30063 Screw, Torx T-30, 1/4-20 x 1/2"
290 30962 Fuel Line 370 36261 Instruction Decal
292 26460 Fuel Line Clamp 370A 35703 Throttle Decal
298 650665 Screw, 1/4-15x3/4" 370B 35532 Logo Decal
300 34186A Fuel Tank (Incl. 292 & 301) 370C 35274 Instruction Decal
301 35355 Fuel Cap 380 632689 Carburetor (Incl. 184)
305 35554 Oil Fill Tube 390 590671 Rewind Starter
307 35499 “0”-Ring Note: This engine could have been built
308 35540 Fill Tube Clip with 590704 starter. Refer to the design of the
310 36205 Dipstick air intake louvers for part identification.
325 29443 Wire Clip Individual starter parts do not interchange.
327 35392 Starter Plug 400 36454 Gasket Set (Incl. Part Nos.
339 35880 Spacer 27272A, 27896A, 27915A, 29673,
340 34259 Fuel Tank Bracket 33263, 33629, 34698A, 35262 &
341 34258A Fuel Tank Bracket 36448)
RPM Setting:
High Speed: 3450 to 3750
Low Speed: 1700
OPTIONAL SPARK ARRESTER
Part No. 34479A
22
