No. Description Part No. Qty.
1 BIADE ASSEMBLY (R. H,)
Includes:
LM-01053-90 1
2 TINE-blade (left hand) LM-01053-75 2
3 SCREW-hex cap, 7/16-20 x 2 LM-07150-95 4
4 SPACER LM-01053-77 4
5 TINE BLADE (right hand) LM-01053-76 2
6 NUT-hexlock, 7/16-20 LM-09148-80 4
7 PLATE-tine LM-01053-84 1
8 PIN-cotter, 1/8 X 3/4 LM-09184-51 4
9 PIN LM-01180-53 2
10 PIN-inner LM-01052-49 2
11 BLADE ASSEMBLY-inner (R. H.)
Includes:
LM-01053-87 1
12 TINE-blade (left hand) LM-01053-75 2
13 SCREW-hex cap, 7/16-20 x 2 LM-07150-95 4
14 SPACER LM-01053-77 4
15 TINE-blade (right hand) LM-01053-76 2
16 NUT-hex lock, 7/16-20 LM-09148-80 4
17 HUB-attachment LM-01053-81 1
18 KEY LM-01053-37 4
19 BLADE ASSEMBLY-inner (L. H.)
Includes:
LM-01053-88 1
20 TINE-blade (left hand) LM-01053-75 2
21 SCREW-hex cap. 7/16-20 x 2 LM-07150-95 4
22 SPACER LM-01053-77 4
23 TINE-blade (right hand) LM-01053-76 2
24 NUT-hex lock, 7/16-20 LM-09148-80 4
25 HUB-attachment LM-01053-81 1
26 BLADE ASSEMBLY (L. H.)
Includes:
LM-01053-89 1
27 TINE-blade (left hand) LM-01053-75 2
28 TINE-blade (right hand) LM-01053-76 2
29 SPACER LM-01053-77 4
30 SCREW-hex cap, 7/16-20 x 2 LM-07150-95 4
31 NUT-hex lock LM-09148-80 4
32 PLATE-tine LM-01053-84 1
33 PLATE-end, deflector (right hand) LM-01052-74 1
34 BOLT-carriage, 5/16-18 x 1/2 LM-07030-11 8
35 WASHER-lock, 5/16 LM-09173-56 15
36 NUT-hex, 5/16-18 LM-09173-72 15
37 DEFLECTOR-right hand LM-01053-69 1
38 SCREW-hex cap, 3/8-16 x 1 LM-09212-10 5
39 WASHER-lock, 3/8 LM-09169-65 8
40 SCREW-hex cap, 3/8-16 x 5/8 LM-07150-24 1
41 SCREW-hex cap, 3/8-16 x 7/8 LM-09193-57 2
42 BOLT-carriage, 5/16-18 x 3/4 LM-09194-14 7
43 SHIELD LM-01053-54 1
44 CHANNEL-reinforced LM-01053-30 1
45 NUT-hex, 3/8-16 LM-09169-50 2
46 PLATE-end, deflector (left hand) LM-01052-73 1
47 DEFLECTOR-left hand LM-01053-70 1
DECAL-safety LM-01030-31 1
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
