No.
Description
Part No.
Qtj
1
FITTING-grease
LM-09150-19
2
2
BOLT-(R. H. side)
LM-01051-32
2
3
WASHER-lock, 1/2
LM-09169-66
5
4
SIDE BAR
LM-01053-20
2
5
NUT-full hex, 5/16-18
LM-09173-72
4
6
WASHER-lock, 5/16
LM-09173-56
4
7
BEARING
LM-01053-11
2
8
LCXiKNUT-full hex, 5/16-18
LM-09233-62
14
9
HALF CASE ASSEMBLY (R. H.)
LM-01053-66
1
10
NUT-full hex, 1/2-13
LM-09169-51
1
11
WASHER-flat, 1/2
LM-09184-31
2
12
SCREW-thread forming,
3/8-16 X 1-1/2
LM-07150-91
6
13
BEARING
LM-01053-09
2
14
SEAL
LM-01053-65
2
15
UPPER BEARING PLATE
ASSEMBLY
LM-01053-13
2
16
Includes: (each assembly)
SCREW-hex cap, 5/16-18 x 1-1/2
LM-09212-21
2
17
SEAL
LM-01053-57
2
18
PLATE-reinforcing
LM-01053-07
2
19
NUT-hex lock, jam, 3/8-16
LM-09287-31
6
20
SPACER
LM-01053-60
2
21
BEARING-roller
LM-01051-95
4
22
RING - r eta ining
LM-01051-94
4
23
WASHER
LM-82810-14
4
24
PULLEY SHAFT ASSEMBLY
LM-01052-98
1
25
SPACER-intermediate
LM-01051-92
1
26
SPROCKET ASSEMBLY
LM-01053-01
1
27
CHAIN
LM-01053-45
1
28
TINE SHAFT ASSEMBLY
LM-01052-97
1
29
CHAIN
LM-01053-36
2
30
SPROCKET ASSEMBLY
LM-01052-91
1
31
SPACER-intermediate
LM-01052-92
1
32
SCREW-hex cap, 5/16-18 x 5/8
LM-09193-18
14
33
SCREW-hex cap, (L. H.)
1/2-20 X 1-1/4
LM-07060-22
2
34
SCREW-hex cap, 1/2-13 x 4
LM-07050-68
1
35
HALF CASE ASSEMBLY (L. H.)
LM-01053-67
1
36
GASKET
LM-01053-73
1
GREASE CAP
LM-01053-63
2
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
