GETTING READY
24
4. Turn off the camera
and remove its
connector cover.
5. Set the camera onto
the USB cradle.
• The CHARGE lamp on
the USB cradle should
turn red, indicating that
charging has started.
When charging is
complete, the CHARGE
lamp will turn green.
6. After charging is complete, remove the camera
from the USB cradle and replace the connector
cover.
CHARGE lamp
Connector cover
To charge the battery
1. Connect the AC power cord to the AC adaptor.
2. Plug the other end of the AC power cord into a
household power outlet.
3. Connect the AC adaptor to the DC IN 5.3V con-
nector of the USB cradle.
AC Adaptor
DC IN 5.3V
USB Cradle
AC power cord
