GETTING READY
18
F
G
F
Connector cover
G
Memory card slot
If you are not using a memory card, be sure to insert the
dummy card into this slot to protect against dust and
damage.
■
Bottom
H
Be sure to replace the
connector cover whenever
the connector is not being
used.
H
Connector
*
Connection of an LCD
remote controller is
supported by the EX-M1
only.
USB Cradle
Simply placing your CASIO digital camera onto the USB
cradle lets you perform the following tasks.
• Battery charging (page 24)
• Automatic transfer of images to a computer (page 87)
Removing the Connector Cover
1
Camera connector
2
USB lamp
3
CHARGE lamp
1 2
3
4
5
■
Back
4
USB
(USB port)
5
DC IN 5.3V
(AC adaptor connector)
■
Front
