34

Speaker Impedance Table

Speaker
Impedance

# of Speakers

How Connected

Overall
Impedance

2 Ohms

1

-

2 Ohms

2 Ohms

2

Series

4 Ohms

2 Ohms

2

Parallel

1 Ohm

2 Ohms

3

Series

6 Ohms

2 Ohms

4

Series

8 Ohms

2 Ohms

4

Series/ Parallel

2 Ohms

4 Ohms

1

-

4 Ohms

4 Ohms

2

Series

8 Ohms

4 Ohms

2

Parallel

2 Ohms

4 Ohms

3

Series

12 Ohms

4 Ohms

3

Parallel

1.3 Ohms

4 Ohms

4

Series

16 Ohms

4 Ohms

4

Parallel

1 Ohm

4 Ohms

4

Series/ Parallel

4 Ohms

8 Ohms

1

-

8 Ohms

8 Ohms

2

Series

16 Ohms

8 Ohms

2

Parallel

4 Ohms

8 Ohms

3

Parallel

2.6 Ohms

8 Ohms

4

Parallel

2 Ohms

8 Ohms

4

Series/ Parallel

8 Ohms
