25
i-5100 Specifications
Output Power Rating Power
Stereo Output 4 ohm @ 14.4V (0.05%) 4 x 50 / 2 x 25 / 1 x 400 W
Stereo Output 2 ohm @ 14.4V (0.05%) 4 x 80 / 2 x 35 / 1 x 600 W
Bridged Output 4 ohm @ 14.4V (0.05%) 2 x 175 / 1 x 78 / 1 x 600 W
Channel separation (Full Rated Power) > 50dB
THD Distortion with 22k Filter 0.10%
Frequency Response (-3dB) 10 - 25KHz
S/N Ratio (A-Weighted) > 90dB
Input Gain Control
Low Level Input 150mV — 4V
High Level Input 450mV — 12V
Input Impedance 20kΩ
Features
Battery Voltage Range for Operating
10.5V — 16V
LED Indicator Red/Green
Protection (Short, Thermal, Overcurrent) Yes
Crossover HP/FULL/LP
Variable Hi-Low Pass 40Hz — 400Hz
Crossover Slope 12dB/Octave
Bass EQ at FULL/LP at 45Hz 12dB
Dimensions mm / in.
Length
817mm / 24.5 in.
Width 273mm / 10.75 in.
Height 57mm / 2.25 in.
