31
i-1200 Specifications
Output Power Rating Power
Mono Output 4 ohm @ 14.4V (0.1%) 1 x 980W
Mono Output 2 ohm @ 14.4V (0.1%) 1 x 1200W
THD Distortion with 22k Filter < 0.1%
Frequency Response (-3dB) 10 - 250Hz
S/N Ratio (A-Weighted) > 95dB
Input Gain Control
Low Level Input 150mV — 4V
High Level Input 450mV — 12V
Input Impedance 20kΩ
Features
Battery Voltage Range for Operating
9V — 16V
LED Indicator Red/Green
Protection (Short, Thermal, Overcurrent) Yes
Crossover Lowpass
Crossover Slope 12dB/Octave
Bass EQ at LP at 45Hz 12dB
Dimensions mm / in.
Length
425mm / 16.75 in.
Width 273mm / 10.75 in.
Height 57mm / 2.25 in.
