Page 13: Resistances
Page 11
60706-130
7150-01
REF
DESCRIPTION
QTY
PART NBR.
001
Cap Screw 5/16”-18x2 3/4
4
51101-000
002
Lockwasher 5/16”
4
480-000
003
Lockwasher Split Type ¼”
3
479-000
004
Machine Screw
3
45633-000
005
Lockwasher 11/16 Int.
1
40552-000
006
Flat Washer
1
21867-000
007
Lockwasher
1
20039-000
008
Hex Nut 1/2-20
1
9549-000
009
Lockwasher
2
636-000
010
Cap Screw 1/2-13 x 1
1
48178-000
011
Machine Screw
4
44342-000
012
Lockwasher
5
6376 -000
013
Hex Nut 8-32
5
5113-000
014
Machine Screw
28
40746-000
015
Cap Screw 7/16-20 x1 3/4
7
43781-000
016
Cap Screw 7/16 -20 x 1 1/2
1
54806-000
400
Generator
1
61367-002
401
Fan Assembly
1
23404-000
411
End Bracket
1
51046-003
412
Oil Seal
1
46912-000
413
Bearing
1
46913-000
414
Retainer Plate
1
44318-000
415
Gasket
1
20136-000
416
Spacer
1
20137-000
417
Pinion Gear
1
46545-000
418
Key
1
20159-000
419
Lockwasher
1
20139-000
REF
DESCRIPTION
QTY
PART NBR.
420
Hex Nut
1
20160-000
430
Armature Assembly
1
64794-000
431
Armature
1
64794-001
432
Bearing
1
50215-000
440
Field Shell & Coil Assembly
1
61368-002
441A Field Coil
1
64787-000
441 B Field Coil
1
64787-001
442
Pole Shoe
2
43473-000
443
Pole Shoe Retainer
2
43474-000
444
Field Shell
1
61153-001
447
AC Brush
12
24981-000
448
Lead Shield
1
23478-000
449
Brush “Q”
2
53949-000
460T
Brush Rack Assembly
1
53977-000
460B Brush Rack Assembly
1
53977-001
462
Brush Holder
12
23500-002
463
Condenser
3
41221-000
467
Rectifier
1
91452-000
468
Ground Strap
1
41387-007
469
Spacer
14
23532-000
470
Brush Holder Spacer
2
52559-000
471
Mounting Plate
6
53975-000
472
Brush Holder “Q”
2
23500-000
491
End Cover
1
55438-023
610
Base
1
51147-000
N/I
Wiring Harness
1
64543-000
GENERATOR REPLACEMENT PARTS LIST
N/I - Not Illustrated
TECHNICAL DATA
Generator Specifications:
kW - 20; Volts -120/240; Amps - 83; PH - 1; Hz -60;
Input - 1000/1182 RPM; Generator - 3600 RPM
Resistances:
Field Coils (rectifier circuit) 17.1 - 18.8 Ohms; Excitor Volts - 92, Amps 2.4
Field Coils (regulator circuit) 11.2 - 12.6 Ohms; Excitor Volts - 55, Amps 2.8 (full load)
Armature (Q Winding) .080 - .088 Ohms, (G1 to N & G3 to N) .025 - .0275 Ohms
